| 原産地: | 中国(本土) | 銘柄: | hosn | モデル番号: | lhd 450 13 | 使用法: | デッサン | タイプ: | スリップ | マックス。ライン速度( m/s): | 20 | 描画キャプスタン径。(ミリメートル): | 450 | マックス。描画死ぬ: | 13 | メインモータ( kw): | 315 | キャプスタン電源( kw): | 75 | 総電力( kw): | 470 |
包装
| 包装: | 耐航性のあるパッキング; 燻蒸の自由のカートン; 電気部品のための真空包装 |
LHD 450 9 rod breakdown drawing machine by aluminum
1.GENERAL DEscriptION
This machine is used to draw Ø2.5- Ø5.0mm aluminum wires from Ø 7.6mm aluminum rod. The drawing blocks are mounted in one row. The constant-speed wheel and the other 8 drawing blocks are driven by two motors respectively. Such design makes it easy to operate and change dies quickly.
2.TECHNICAL PARAMETER
| Items | Specification |
2.1 | Inlet wire diameter | Ø9.5mm |
2.2 | Outlet wire diameter | Ø2.2- Ø5.0mm |
2.3 | Max drawing speed | 20m/s |
2.4 | Drawing capstan diameter | Ø450mm |
2.5 | Max. drawing dies/ capstans | 13 |
2.6 | Die dimension | Ø38mm×25mm |
2.7 | Capacity of the accumulator | 7m |
2.8 | Dual-bobbin take up size | PND500~PND630 |
2.9 | Main motor power | 315KW (DC) |
2.10 | Power of motor for constant speed wheel | 75KW (DC) |
2.11 | Power of motor for dual-bobbin take up | 30 KW×2 (DC ) |
2.12 | Machine dimension(L×W×H) | 20000×45000×48000mm |
