| 原産地: | 中国(本土) | 銘柄: | KND waterproof rotary switch,2 or 3 position selecor key switch | モデル番号: | rotary switch,2 or 3 position selector key switch LA167-B2-BG | 機械生命: | 100000times | 最高。 電圧: | 380V | 最高。 現在: | 15A |
包装
| 包装: | 防水ロータリースイッチ、 2または3ポジションセレクターキースイッチはカートンでパッケージ化する。 我々はまた、 を追加することができpp袋外防水ロータリースイッチ、 2または3ポジションセレクターキースイッチカートン湿気を防ぐために。 200個防水ロータリースイッチ、 2または3ポジションセレクターキースイッチに包装するカートン。 各防水ロータリースイッチ、 2または3ポジションセレクターキースイッチは10箱カートン。 各ボックス20個を持ってい防水ロータリースイッチ、 2または3ポジションセレクターキースイッチ。 |
仕様
Description
| waterproof rotary switch,2 or 3 position selector key switch Technical Parameters | |||||
| Nominal insulation voltage Ui(V) | 380V | ||||
| Rated current lth(A) | 10A | ||||
| Rated operational voltage ue(v) | 380 | 250 | 240 | 125 | |
| Rated operationalcurrent le(A) | AC-15 | 2.5 | 3 | ||
| DC-13 | 0.27 | 0.55 | |||
| waterproof rotary switch,2 or 3 position selector key switch Environment Features | |
| Match a standard | CB14048 5-2008,IEC 60947-5-1 |
| Ambient temperature | -25°c- +55°c |
| Vibration resistance | ≤ 500HZ , amplitude about 1.0mm |
| Shock resistance | ≥10g |
| Protection level | IP40,IP65 |
| waterproof rotary switch,2 or 3 position selector key switch Contact Features | |
| Contact action | NO or NC |
| Contact resistance | ≤ 50mQ |
| Mechanical life | ≥1000000 |
| Electrical durability | AC ≥100000 |
| Short-circuit protection | RT16-10A |
| Elucidation | Contact Type | Reference | ||
| 2 choice |
PACKAGING 1 If the selector key switch quantity is big enough ,we can do the packaging according to your requirement and in your brand .There is no extra charge for you. 2 Each selector key switch is sealed by polythelene bag .It can be always in good condition no matter how long it is in stock. 3 Every box also is sealed by polythelene bag,protecting the selector key switch from water.Even though selector key switch is shipped by sea. 4 The selector key switch are using standard packaging.
EXPORTING 1 Our customers are all around the world and the quantity demand is large.After the payment ,the selector key switch samples will be sent ASAP. 2 After confirming the payment ,the selector key switch samples will be sent by DHL,UPS,FEDEX and so on . 3 We can help your agent which in china to deal with the exporting process. 4 The selector key switch also can be exproting by your trading company . 5 You can contact our sale department for more details
