原産地: | 中国(本土) | モデル番号: | Ae-1 | プラスチックタイプ: | PVC | 処理される材料: | フィルム |
Technical data:
Machine dimension: 1670780x1800mm
Net weight: around 800kg
Power: AC380V/50-60Hz 5KW
Air source: 6Kg/cm2 (without water)
Control mode: Stepping system + PLC
Production capacity: 4000pcs/hour
Feature: It is a quick machine combined with big font embossing, small font embossing,
tipping and card collecting
Dual hydraulic punching head offer sufficient force with good stability. Working speed and embossing stroke are adjustable.
Easy to set on touch screen to emboss big fonts, small fonts and tipping to work together or separately
Big or small fonts can list max 20 digits, which can meet requirement of a standard credit card
Symbol position can be freely adjusted within 3.0mm to the length side of the card.
Symbol position discrepancy is less than +/- 0.5mm to right/left, and ±0.25mm to up/down
PLC control, fully automatic, it will alarm automatically if there is any error
Touch screen offer easy operation Tipping foil stepping distance is adjustable, raising the foil using efficiency
Specially design dual card stock recycling card-collecting, reduce disorder phenomenon
Embossed fonts is beautiful, full with excellent tipping result.
