Technical data:High-speed automatic wrapping machine

Power supply: AC 380V/50 Hz

Total power: 3.5KW

Air source: 6Kg/cm2

Weight: 600Kg

Production capacity: max 25000 pieces/ hour

Control type: PLC control+ servo system

Wrapping film: 0.25-0.35 um BOPP film

Wrapping specification: Width 120mm (half-folded), or 240mm (unfolded)

Card specification: CR80 ISO/IEC7810 54X85.6mm

Dimension: L4300-W780-H1060mm

Feature: Combine film conveying, card conveying, packing, material distributing and material
collecting.
You can choose single card or two card conveying. If you choose two card conveying at the same time, you can pack two cards in one bag.
Suitable to all kinds of packing film with thickness over 0.025mm Suitable to pack all kinds of standard card with thickness over 0.25mm (paper card, PVC card, ABS card, etc.)
Piled cards or code automatically checked, machine will stop if there is any error
Easy to change the mold, packing bag size can be adjusted Packing film conveying use special rubber roller which ensure tension, stable and smooth conveying
Using ultra-sonic welding which ensure clear and beautiful artwork Poly-bag side use personalization design, the artwork can be designed as per your own requirement.
Card collecting quantity can be pre-set
