| 原産地: | 中国(本土) | 自動等級: | 自動 | タイプ: | ラミネート・マシン | 条件: | 新しい | 使用法: | 外 | タイプ: | 特別 |
Control type: Servo-system plus PLC control
Production capacity: 12,000 pcs/hour
Electric power:AC380V, 50-60Hz
Air pressure: 6kg/cm2 without water
Production capacity: around 12000pieces/hour
Power: 3.3KW
Dimension: 1700950x1200mm
Weight: 900k
Easy-use touch screen
Oil-cylinder type hydraulic punching knife
Horizontal location and high sensitive photo-electricity coordinate with two groups of stepping system, realizing both X and Y directions two-way locating.
Locating precision is smaller than 0.10mm
Punching knife mold type: two, three, four or five molds which offer you flexible choice
Automatic adjust-locating
Low working noise
Oil and air pressure both are adjustable, alarm automatically
Oil cylinder route is adjustable
Oil temperature is low, stale and reliable
Quick and high-precise
