| 原産地: | 中国(本土) | 銘柄: | eshinede | モデル番号: | EB281763617493 |
色: | 参照画像 |
包装
New 12V 4Ch Bluetooth Relay Android Mobile Remote control Switch for Motor LED Light
Product Des
cription
Typical applications: Home lighting systemRemote co
ntrol switchRemote lockingSmart Home / Home Automatio
nDC 12V LED lightingFluorescent lamp12V DC MotorFluorescent lampAutomotive electro
nicsPLCIndustrial automation and control 1 DC 12V co
ntrol circuit,Wiring diagram below. "LOAD" may be LED lights, fans, motors and other DC 12V equipment
Bluetooth relay manual:
USE:1 Click to find Bluetooth devices2 Search for Bluetooth devices3 Click mating connector,4 The first co
nnection requires a password, the default password is: 12345 After a successful connection, the indicator is no lo
nger flashing.
Glossary:
NO : Relay normally open contact
COM : Relay common contact
NC : Relay normally closed contact
Momentary : Mobile terminal input "A0" (B0 / C0 / D0 is the same), the relay is "open",and after delay of 1 second the relay is "Close".
Self-locking : Mobile terminal input "A1", the relay is "Open", input "A1", the relay is "Close", and so on
Interlock : Mobile terminal input "A2", relay 1 is "Open", the other relay is "Close"; input "B2", relay 2 is "Open", the other relay is "Close", and so on.
Open : NO connection COM, NC disconnect COM
Close : NO disconnect COM, NC connection COM
CommandS (Format: character, case-insensitive)
CommandS | Features | Description |
A0 | CH1 "Momentary" | Mobile terminal input "A0", the relay is "open",and after delay of 1 second the relay is "Close". |
A1 | CH1 " Self-locking " | Mobile terminal input "A1", the relay is "Open", input "A1", the relay is "Close", and so on |
A2 | CH1 " Interlock " | Mobile terminal input "A2", relay 1 is "Open", the other relay is "Close"; Input "B2/C2/D2" relay 1 is "Close" |
A3 | CH1 " Open " | NO1 connection COM1, NC1 disconnect COM1 |
A4 | CH1 " Close " | NO1 disconnect COM1, NC1 connection COM1 |
B0 | CH2 "Momentary" | Mobile terminal input "B0", the relay is "open",and after delay of 1 second the relay is "Close". |
B1 | CH2 " Self-locking " | Mobile terminal input "B1", the relay is "Open", input "B1", the relay is "Close", and so on |
B2 | CH2 " Interlock " | Mobile terminal input "B2", relay 2 is "Open", the other relay is "Close"; Input "A2/C2/D2" relay 2 is "Close" |
B3 | CH2 " Open " | NO2 connection COM2, NC2 disconnect COM2 |
B4 | CH2 " Close " | NO2 disconnect COM2, NC2 connection COM2 |
C0 | CH3 "Momentary" | Mobile terminal input "C0", the relay is "open",and after delay of 1 second the relay is "Close". |
C1 | CH3 " Self-locking " | Mobile terminal input "C1", the relay is "Open", input "C1", the relay is "Close", and so on |
C2 | CH3 " Interlock " | Mobile terminal input "C2", relay 3 is "Open", the other relay is "Close"; Input "A2/B2/D2" relay 3 is "Close" |
C3 | CH3 " Open " | NO3 connection COM3, NC3 disconnect COM3 |
C4 | CH3 " Close " | NO3 disconnect COM3, NC3 connection COM3 |
D0 | CH4 "Momentary" | Mobile terminal input "D0", the relay is "open",and after delay of 1 second the relay is "Close". |
D1 | CH4 " Self-locking " | Mobile terminal input "D1", the relay is "Open", input "D1", the relay is "Close", and so on |
D2 | CH4 " Interlock " | Mobile terminal input "D2", relay 4 is "Open", the other relay is "Close"; Input "A2/B2/C2" relay 4 is "Close" |
D3 | CH4 " Open " | NO4 connection COM4, NC4 disconnect COM4 |
D4 | CH4 " Close " | NO4 disconnect COM4, NC4 connection COM4 |
Bluetooth APP operations:Access Password : 1234
Bluetooth Baud rate: 9600BPS
