| 電圧: | 380ボルト、415ボルト、440ボルト、460ボルト | 原産地: | 中国(本土) | 銘柄: | ディングリ | 製品容量: | 1479L/時間 | モデル番号: | XMY100/1250-30u | 重量: | 3970キログラム | 自動等級: | 自動 | 力(W): | 4kw | 保証: | 12ヶ月 | 条件: | 新しい | 認証: | iso、ce | 次元(L*W*H): | 5020 × 1880 × 1600ミリメートル | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | フィルタープレートサイズ: | 1250 × 1250 | フィルタープレート材料: | tpeエラストマー | フィルター布サイズ: | 1350 × 1350 | フィルター布素材: | ポリプロピレン繊維 | フィルタープレート数量: | 36 | フィルター面積: | 100㎡ | プレートオープンと放電: | 自動プルボード | 制御: | plc | 建設材料: | 炭素鋼/ステンレス鋼 |
包装
| 包装: | ビニール袋パッキング |
Manual Plate And frame Filter Press
Our company supply various series of filter presses, including chamber filter press, plate and frame filter press, stainless steel filter press, lab type filter press, automatic filter press, water washing filter press, cast iron filter press, vertical filter press, etc.
Introduction of Plate and frame Filter Press:
Manual plate and frame filter press is a kind of interval solid-liquid separation equipment, is by the filter plate, filter box arrange a filter chamber (plate and frame type), under the action of the pressure of transporting pump, sending material liquid into the filter chamber, through the filter cloth filter to separate solid and liquid. Widely used with the chemical industry, dyestuff, oil, ceramics, pharmaceutical, sugar, food, starch, sugar, paint, the coal, metallurgical and smelting industries of sewage treatment, etc.
Plate and frame filter press in accordance with the way of working can be divided into manual type plate and frame filter press, fully automatic plate and frame filter press, semi-automatic plate and frame filter press; Plate and frame filter press can also according to the important component of filter plate to distinguish, common polypropylene plate and frame filter press, rubber plate and frame filter press, etc.
Structure of Plate and frame Filter Press:
Manual plate and frame filter press, respectively, by the filter frame, filter cloth, filter plate and filter plate filter cloth of the filter and the filtering part compression (handwheel, jack) chassis parts, thrust plate end hole, feed opening, respectively, into the hole, washing liquid filtrate discharge collecting liquid hole, washing liquid discharge collecting liquid hole and so on. According to the filter type you choose, pick up line.
Technical Specification of Plate and frame Filter Press:
Model | Filter area | frame size | frame thickness | frame qty | Plate qty | Filter chameber volume | Filter pressure | Screw tension pressure | Pressing plate displacement | Weight | Dimensions | remarks | ||||||||||||||||||||
m2 | mm | mm |
|
| m3 | MPa | N | mm | kg | mm |
| |||||||||||||||||||||
2 BMS 4/320 6 | 2 4 6 | 320×320 | 25 | 10 20 30 | 9 19 29 | 0.025 0.050 0.075 | 1.0 | 200,000 | 250 | 520 820 1120 | 1240×550×610 1690×550×610 2140×550×610 | Cast iron | ||||||||||||||||||||
8 BMS 12/450 16 | 8 12 | 450×450 | 25 | 20 30 40 | 19 29 39 | 0.10 0.15 0.20 | 1.0 | 440,000 | 400 | 1700 2000 2490 | 2495×920×900 3000×920×900 3500×920×900 | |||||||||||||||||||||
| 20 30 | 630×630 | 25 | 26 38 50 | 25 37 49 | 0.26 0.38 0.50 | 0.8 | 510,000 | 500 | 3660 5120 6580 | 3170×1260×1200 3810×1260×1200 4460×1260×1200 | |||||||||||||||||||||
| 6 9 13 | 425×425 | 30 | 16 26 36 | 15 25 35 | 0.10 0.15 0.20 | 0.6 | 350,000 | 400 | 1060 1160 1240 | 2495×920×900 3000×920×900 3500×920×900 | Plastics | ||||||||||||||||||||
| 17 25 33 | 600×600 | 30 | 23 | 22 32 42 | 0.26 0.38 0.50 | 0.6 | 350,000 | 500 | 1860 2460 3060 | 3170×1120×1200 3810×1120×1200 4460×1120×1200 | |||||||||||||||||||||
| 7 10 | 440×440 | 35 | 17 | 16 24 32 | 0.115 0.170 0.220 | 0.6 | 200,000 | 400 | 1100 1350 1550 | 2495×920×900 3000×920×900 3500×920×900 | Plastics | ||||||||||||||||||||
| 17 25 | 620×620 | 35 | 22 | 21 31 41 | 0.295 0.435 0.565 | 0.6 | 200,000 | 500 | 2400 2850 3200 | 3170×1120×1200 3810×1120×1200 4460×1120×1200 | |||||||||||||||||||||
| 6 | 440×440 | 35 | 15 | 14 21 28 | 0.10 0.15 0.20 | 0.6 | 200,000 | 400 | 1050 1250 1600 | 2495×920×900 3000×920×900 3500×920×900 | rubber | ||||||||||||||||||||
| 15 | 620×620 | 35 | 19 | 18 27 36 | 0.26 0.38 0.50 | 0.6 | 200,000 | 500 | 2400 2750 3100 | 3170×1120×1200 3810×1120×1200 4460×1120×1200 |
