| 原産地: | 中国(本土) | 銘柄: | いすゞ | モデル番号: | 4jb1 | 燃料: | ディーゼル | 打撃: | 4打撃 | シリンダー: | 多シリンダー | 冷たい様式: | Water-cooled | 使用法: | 自動車 | 開始: | 電気開始 |
包装
| 包装: | 合板カートン |
Isuzu diesel engine 4JB1,4JB1T with Japanese Isuzu technology.
Very good performance and reliable, widely used for light truck,Npr truck, pickup etc.
Complete engine are under warranty for 1 year.
specification info as below:
| Isuzu 4JB1 and 4JB1T | ||
| Model | 4JB1 | 4JB1T |
| bore*stroke | 93mm*102mm | |
| type | 4 cylinders in line, water cooled, 4 stroke, direct injection | |
| displacement | 2.771L | |
| compression ratio | 18.2:1 | |
| ignition order | 1-3-4-2 | |
| lubricating method | forced and splash lubrication | |
| rated power | 57kw | 68kw |
| rated speed | 3600rpm | 3600rpm |
| max torque | 172N.m at 2000rpm | 200N.m at 2000rpm |
| output power per liter | 20.6kw per liter | 24.5kw per liter |
| minimum fuel consumption | ≤221g/kw.h | ≤221g/kw.h |
| overall dimension | 850mm*630mm*750mm | |
| net dry weight | 230kg | 245kg |
| emission level | Euro I, Euro II | Euro I, Euro II |
