| 原産地: | 中国(本土) | 電圧: | 220av | 銘柄: | フェートン | 寸法 (L*W*H): | l3、080W990xH1、260ミリメートル | モデル番号: | UD-1812LB | 重量: | 204キログラム | 自動等級: | 自動 | タイプ: | インクジェット式プリンタ | 色及びページ: | 多色刷り | 全体のパワー: | 2000ワット | 認証: | ce | 使用法: | 布プリンター | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 版のタイプ: | 平面プリンター | 条件: | 新しい | 印刷インタフェース: | usb2.0 |
包装
| 包装: | 木製パッケージl3190w1100xh845mm/390kg |
Digital Textile Printing Machine 1.8m UD-1812LB Sublimation Printer with Epson Dx5 Head
Features:
1.fast speed,original epson dx5 head,with 8 columns ,incluidng 1440 nozzles,
print high resolution
2.used for printing textile,fabric,and other polyester material
3. full aluminum platform and bearing rail stable and long durability
4.X.Y axis AC servo motors
5.standard print 25.sq.m./h
Specification:
| Model No. | UD-1812LB |
| Printhead | Micro piezo printhead :2 Epson dx5 printheads |
| Color | Double 4 color :C-2 M-2 Y-2 K-2 |
| Print Width | 1800mm |
| MaximumPrinting Resolution | 1440dpix1440dpi |
| Printing Speed(m²/h) | Draft model : 2 Pass 40 sq.m./h |
| Standard model : 3 Pass 25 sq.m./h | |
| Quality model : 4 Pass 22 sq.m./h | |
| High quality model : 6 Pass 15 sq.m./h | |
| Ink | Type : Disperse Dye |
| Color : 4 Color (C,M,Y,K) | |
| Ink Capacity | 1L per Main Tank of Each Color |
| Media | Heat Transfer Paper,Polyster,Satin,Warp Knitted,Mesh Knitted fabric,Flag banner fabric ect. |
| Maximum Width: 1,880mm | |
| Pre-heating & Drying System | Equipped |
| Clamp | Equipped |
| Auto Media Feeding & Take- up System | Equipped(Max. Media Weight 25kg) |
| Auto Cleaning System | Anti-Clogged Flash Function & Capping System |
| Rip Software | Ultraprint,Maintop,Photoprint,Wasatch |
| Interface | USB 2.0 |
| Operation System | Windows XP |
| Input Power | AC 220, 50Hz/60 HZ |
| Woking Environment | Temperature : 20 - 25 ,Humidity : 40 -70 % |
| Machine Dimension /N.W | L3,080 x W 990 x H 1,260mm / 204KG |
| Package Dimension / G.W | L3,190 x W 1,100 x H 840 mm / 390 KG |
Package and Delivery:
We could provide professional package and fast delivery, make it complete to you.
We are specialized supplier,the products including:
A.Infiniti/Challenger/Phaeton/Galaxy/Icontek printer
B.Solvent ink,Eco Solvent in for kinds of printers
C.printer parts
If you need any help,please feel free to contact us.
We are always here.
Hope to cooperate with you.
