| 原産地: | 中国(本土) | 銘柄: | cmax | モデル番号: | cmax | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | マシンタイプ: | フル-自動チェーンリンク機/半自動機 | 電源: | 220ボルト380ボルト440ボルトなど | ワイヤー直径: | 5〜12ミリメートル | 横糸ワイヤー距離: | 100〜300ミリメートル | 定格電圧: | 380ボルト50 ｈｚ | 定格電力: | 125kva × 12 |
包装
| 包装: | プラスチックフィルム |
1. Structure of Welded Wire Mesh Machine
This equipment is the mechanical electronic computer integration and advanced welds the net equipment,this machine biggest characteristic is the organzine may adjust may appear between the latitude and the latitude on the identical standing net the different size hole,the welding transform voltage uses the new highly effective transform votage mesh,the wire diameter scope which the expansion may weld.Also this machine welds the net piece smoothly,diagonal line error small,is easy to operate.The flexibility is the ideal equipment which the net fence welds.
Chain link machine for manufacturing chain link fences of different sizes. The wire is taken in from the payoff stand and passed through the dies wher the DIAMOND SIZE takes place. Different gap sizes. After passing from the die the diamond pattern wire is automatically thrown on the winding shaft in the stitching process. Once the stitching is complete the woven is manually glided down to enable the next stitch to take place.
2 . Main features of Weleded Wire Mesh Machine
1.This machine adopts synchronous control technique, both the welding time and cent-control welding is supervised by IPC.
2. It adopts modularization design, so it is easy to improve the machine’s function and feacure.
3. The line wires are fed automatically and continuously, so it saves much welding time to wait. The edges are regular and also could be adjustable.
4. There is a big hopper for cross wires, it could contain one ton wires, it save much labor to add wires. Wire galling is also very precise.
5. It adopts servo motor to pull the mesh repeat, the mesh size are accurate and also could be adjustable.
6. Mesh pulling frame and cross wire falling part all could move to mesh pulling orientation, this could offer the space for orientation, increase the efficiency when adjust the mesh size.
7. The welding power is FM and timing motor, compared with abroad machine whose power is air pressured, this machine has such advantages: firm welding, little noise, high speed, smaller investment, lower maintenance.
3. Welded Wire Mesh Machine Image
