| 原産地: | 中国(本土) | 銘柄: | yinrich | モデル番号: | jem120 | 加工タイプ: | マシュマロ | 加工: | 押し出された |
包装
| 包装: | 耐航性のあるパッキング |
JEM120 Cotton Candy Machine
1.Main specification
Model | JEM120 |
Production capacity kg/h | 60~120 |
Making size (dia.)of the product mm | 20~50 |
Cutting length of the product mm | 20~160mm |
Steam consumption kg/h Steam pressure MPa | 250 0.2~0.6 |
Electric power needed | 35kW/380V |
Compressed air consumption Compressed air pressure | 1.5m3/min 0.6-0.8MPa |
Conditions needed for the cooling system: 1. Room temperature() 2. Humidity (%) |
20~25 45~55 |
Gross weight kgs | 8000 |
Total length of the line m | 25(35) |
2.Equipment list
No. | Description | Specifications | Power(kw) | No. | Remark |
A | Mass preparation section
| 150kgs/h |
|
|
|
1 | Gelatin melting tank | 100L | 0.75 | 2 | SUS304 |
2 | Hipping agent pre-mixer
| 200L | 0.75 | 1 | SUS304 |
3 | Rotary pump |
| 1.1 | 1 | SUS304 |
4 | auto-weighing & dissolving cooker
| AWS-500 |
| 1 | See the photo |
5 | Continuous boiling cooker
| 12001200x2000 | 1.5 | 1 | SUS304 |
6 | Vacuum chamber | 200L | 4 | 1 | SUS304 |
7 | Screw pump |
| 1.5 | 2 |
|
8 | Final mixing and holding tank
| Φ7001500 | 1.1 | 1 | SUS304 |
9 | feeding pump |
| 1.1 | 1 | From the mass to aerator, SUS304 |
| Continuous aerator | CQ300 | 3.7 | 1 |
|
|
|
|
|
|
|
Photo shows of the product:
