| バラスト: | 電子 | 電圧: | 220v | 格子形: | iiii | 原産地: | 中国(本土) | 反射器: | ステンレス | 銘柄: | ccy | 様式を取付けなさい: | Embeded | モデル番号: | CCY2230 | 最高の反射板照明: | led照明 | 光源: | LED |
包装
| 包装: | による梱包箱と木製ケース |
2x2ft led troffer lighting
CCY best design
best troffer lighting parameter
Technical Data CCY2230 | ||
INPUT | operating voltage | 110~240VAC |
AC current | ~0.25A | |
LIGHT SOURCE | illuminant type | SSL / LED |
illuminant count | 488 LEDs,SMD3528 | |
luminous flux | 2500±20 lm | |
colour temp. | cold-, neutral-, warmwhite | |
colour rendering index (CRI) | 75 | |
life cycle | 35,000 | |
power consumption | 30±1W | |
luminous efficiency | 80±2 lm/W | |
CONSTRUCTIONS | casing | PC and aluminium heat sink |
colour | white | |
mounting | grid ceiling | |
product dimensions | 600 x 600 x 50mm | |
product weight | 2.50kg | |
OTHERS | order number | LT2230 |
mark of conformity | CE RoHS | |
protection category | IP20 | |
package dimensions | 650 x 650 x 90mm | |
Weight with package | 3.6kg | |
it should be aging 7days in our factory
