• 解放のカップリング-水圧関連部品
    商品番号: 10592415
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    原産地: 中国(本土) 銘柄: HX モデル番号: DC
    タイプ: 付属品 標準: A-A-59326、MIL-C-27487、DIN 2828 カムレバー: 黄銅
    シーリング: NBR、EPDM、Viton サイズ: " 8 "への1/2 鋳造方法: 投資鋳造
    ピン、リングおよび安全クリップ: めっきされる鋼鉄 Theads:: NPT、BSP

    包装

    包装: あなたの条件に従う国際規格のパッキングまたは。



                                 pipe fitting



    We are Fuzhou Hongxing Machinery Co., Ltd.  in Fuzhou, Fujian Province, China. We mainly supply camlock couplings (cam & groove quick couplings), guillemin coupling, Bauer type coupling, chicago coupling, Ground joint coupling, sandblast coupling, King combination nipple, DIN2817 safety clamp, T-bolt superior clamp, double bolt clamp, whipcheck safety cable, washdown gun, etc.



      1.Production information





      1. standard:



    Our Camlock Coupling are made to standard of A-A-5932( superseding MIL-C-27487 )or DIN2828

       2. size:



    1/2",3/4",1",1-1/4",1-/2",2",2-1/2",3",4",5",6".

       3. Type:

     A,B ,C ,D, E,F, DC,DP

    4. Body materia:

    Stainless steel 316



     5.Cam levers:



    We use stainless steel cam levers.



    6.Pins,Rings and  Safety clips:



    We use stainless steel pins,steel plated rings and safety clips.(Note:Safety clips are only available when required by the client, the client have to pay additional if need safety clips)



      7.Sealings:

    NBR



    EPDm



    VITon

    PTFE envelop gasket,Other materials are available on request.



     8.Theads:

    NPT



    BSP

    (We usually make the female thread parallel BSPP,male  thread tapered BSP)
