    定電流500maに12vacdc12ワット15wmr16ledドライバのためのled電球の光-その他電力供給
    商品番号: 10443614
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    出力電圧: 21v27v〜 原産地: 中国(本土) 銘柄: dadekan
    モデル番号: Ar111- 15a1050ad 入力電圧: 12vac/12vdc 出力電流: 500ma
    出力電力: 15w12〜

    包装

    包装: 、買い手の要件に応じて。



    MODEL

    AR111-15A1050AD

    Input

    Input Voltage

    12VAC/12VDC

    Voltage Range

    12VAC/12VDC

    Start-up Voltage(-25~70°C)

    12VAC/12VDC

    Frequency Range

    47Hz~63Hz

    Power Factor(@25°C)

    /

    AC Current (@25°C)

    0.95A Max.

    Inrush Current (@ 25°C)

    10A Max.

    Output

    Output Voltage Range

    21V~27V

    Output Current

    500mA

    Output Power

    12~15W

    Conversion Efficiency (@25°C)

    85% @12VDC, Full Load

    No-load Output Voltage

    31V Max.

    Line Regulation (@-25~70°C)

    ±5%

    Accuracy Constant(@-25~70°C)

    ±5%

    Set-up Time(@25°C)

    <1S@12VDC

    Temperature Coefficient (@-25~70°C)

    ±0.03%/°C

    Overshoot (@-25~70°C)

    ±5% No-load Rated Voltage

    Output Ripple & Noise

    0<Ta≤70°C

    220mVP-P

    -25≤Ta≤0°C

    550mVP-P

    Protection

    (-25~70°C)

    Input Electrical

    Low Voltage Protection

    /

    Over Voltage Protection

    /

    Output Electrical

    Shorted Circuit Protection

    Hiccup, Auto Recovery

    No-load Protection

    Constant Voltage

    Over Temperature Protection

    /

    Environmental Requirement

    Vibration

    10~500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z, axes

    Impact

    20G/11mS pulse,3times at each X, Y, Z axes

    Storage Temp. & Hum.

    -40°C~85°C; 10%~95%RH  No condensing

    Operating amb. Temp. & Hum.

    -40°C~60°C; 20%~90%RH  No condensing

    Altitude

    3000m

    IPX

    /

    Safety &.

    EMC

    Isolation Resistance

    Input--out: 100M OHMS

    Withstand Voltage

    Input--out: 3KVAC/10mA

    Ground Impedance

    /

    Safety Standards

    IEC 61347-2-13/GB19510.14/UL8750

    EMI

    CE

    /

    RE

    /

    Harmonic Current

    /

    EMS

    CS

    /

    RS

    /

    ESD

    /

    Surge

    /

    Power Frequency Harassment

    /

    EFT

    /

    Interrupt, Drop

    /

    Other

    Dimensions (L * W * H)

    40mm X 40mm X 20mm

    Package

    /

    Cooling Method

    Ventilation Cooling

    Reliability

    Burn-in

    The power supply shall go a minimum of 4 Hours burn-in test under full load condition.

    Design MTBF

    50,000Hrs @25°C, MIL-HDBK-217 Method 2 Components Stress Method

    Design Electrolytic Capacitor Life

    17520Hrs @50°C Full load and units continuously working

    Note

    Measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1 uF & 10uF parallel capacitor.

    Test spare parts: test voltage for 500 VDC, 65% RH @ 25 °C.

    The SPS is considered a component which will be installed into final equipment. The equipment must be re-confirmed that it still meets EMC directives.

    Minimum Negative Load Requirements

    None
