| 構造: | 水管 | 原産地: | 中国(本土) | 銘柄: | ワンダ | 条件: | 新しい | 出力: | 熱湯 | モデル番号: | clhosシリーズ | タイプ: | 一度 | 燃料: | 木質ペレット、 おがくずペレット、 石炭 | 様式: | 縦 | 圧力: | 低圧 | 認証: | ceiso | 使用法: | 産業 | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため |
包装
| 包装: | 標準的なパッケージング |
Vertical automatic biomass boilers
Biomass boiler featurer:
The boiler structure is unique, complete combustion with high efficiency;Large capacity of gasification chamber and unique structure design, make the fuel burn completely, fuel combustion efficiency can reach above 95%.
Feeding system adopts advanced screw rotation drive automatic feeding device, only need one-time filled with the storage silo, can be 1-2 days do not need to feed; Ignition system uses burning machine or heat wire automatic ignition, greatly reducing the stoker workers labor intensity, make boiler use more humanized.
Biomass hot water boiler belong to the Atmospheric pressure hot water boiler, is operating under atmospheric pressure condition, don't need the yearly check, don't need a professional to personnel operation. Boiler overall compact structure, small volume, no need set up tall chimneys, easy installation, the boiler body after heat zinc processing, water quality clean and durable.
Advantages of fuel:
Biomass fuels are pedicled crops or sawdust after processing production of strip environmental protection new energy, it's diameter is 0.8 cm, and length is 4 ~ 5 times it's diameter, broken rate is less than 1.5% ~ 2.0%, dry basis moisture content less than 10% ~ 15%, ash content less than 1.5%, sulfur and chlorine content are less than 0.07%, the nitrogen content is less than 0.5%. The biomass fuel is one of the government key support new rural construction projects, belong to the state support to promote energy conservation, environmental protection biomass fuels, energy conservation, environmental protection and renewable resources, sources extensive.
Range of application:
Widely used in plants greenhouses supply heating; Hotels, guesthouses, sauna bath center, beauty salon, villas, factories, schools and enterprises and institutions,scouring bath,heating and drying with hot water.
Technical parameters:
| model | CLHOS0.058 | CLHOS0.08 | CLHOS0.12 | CLHOS0.18 | CLHOS0.23 | CLHOS0.35 | CLHOS0.48 | CLHOS0.70 | CLHOS1.05 |
| Rated calorific value(Kcal) | 5x104 | 7x104 | 10104 | 15x104 | 20104 | 30104 | 40104 | 60104 | 90104 |
| rated working pressure (Mpa) | 0 | ||||||||
| Rated for the return water temperature (°C) | 85/60 | ||||||||
| heat efficiency (%) | ≥90 ≥91 | ||||||||
| water yield (L) | ≥1000 | ≥1500 | ≥=2200 | ≥3300 | ≥4000 | ≥6000 | ≥8000 | ≥12000 | ≥18000 |
| Refer to the heating area (m2) | 400-500 | 500-700 | 700-1000 | 1000-1500 | 1500-2000 | 2000-3000 | 3000-4000 | 4000-5000 | 7000-8000 |
| Hot and cold water diameter (mm) | 50 | 50 | 50 | 65 | 65 | 80 | 80 | 100 | 125 |
Power consumption | induced draught system (Kw) | 0.37 | 0.37 | 0.37 | 0.37 | 0.55 | 0.55 | 0.75 | 1.1 | 2.2 |
ignition system (Kw) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | |
Feeder System (Kw) | 0.9 | 0.9 | 0.9 | 0.9 | 0.9 | 1.1 | 1.1 | 1.5 | 1.5 | |
| The chimney mouth (mm) | 140 | 140 | 140 | 140 | 202 | 202 | 240 | 260 | 260 |
Size | length (mm) | 1000 | 1200 | 1300 | 1400 | 1500 | 1700 | 1800 | 2400 | 2600 |
wide(mm) | 550 | 550 | 650 | 750 | 850 | 1000 | 1100 | 1250 | 1500 | |
high(mm) | 1080 | 1330 | 1410 | 1500 | 1600 | 1800 | 1950 | 2100 | 2500 | |
| transport quality(Kg) | 300 | 370 | 430 | 510 | 735 | 980 | 1520 | 1860 | 2350 |
| consumption of fuel (Kg/h) | 10 | 15 | 20 | 31 | 42 | 60 | 80 | 120 | 200 |
| Storage bin capacity (Kg) | 100 | 100 | 200 | 200 | 300 | 300 | 400 | 500 | 800 |
