| 原産地: | 中国(本土) | 銘柄: | Sutree/oem | モデル番号: | smts | 機械生命: | â¥10000times | 最高。 電圧: | 250v | 最高。 現在: | 16a | 電圧電流定格使用: | 3a-6a-15a | 電流: | 250v | 接触抵抗: | â¤0.02Ω | 耐電圧: | 1500vac | 絶縁抵抗: | â¥1000mΩ | 開閉寿命スパン: | 10000 | enviromental温度: | -20- 85度 | 环境湿度: | 45％- 95％ | 機械的寿命: | 30以上、 000サイクル | ウェブ: | www。 chinasuntree。 com |
包装
| 包装: | 標準的な輸出カートン |
仕様
sub miniature toggle switch
1) Max. rating current and voltage:16A, 250V AC
2) Contact resistance: ≤50mΩ
3) Insulate resistance: ≥1,000MΩ
4) Dielectric strength: 1,500V
5) Electronic life (cycles): 10,000
6) Shape: Plane,V-Shaped, Arc-Shaped
7) Indication voltage: 2V, 6V, 12V, 24V, 110VAC, 220VAC
8) Cap colors: red (R), green (G), yellow (Y), white (W), blue (S), orange (A), black (B)
9) Single Pole, Single Throw
SPECIFICATIONS
RATING: 9A 125VAC
6A 250VAC
4A 250VAC
MECHANICAL LIFE: 30,000 Cycles
ELECTRICAL LIFE: 10,000 Cycles
ConTACT RESISTANCE: 20mΩ Max. Typical, Initial
INSULATION RESISTANCE: >1,000MΩ
DIELECTRIC STRENGTH: >1,500V for 1 Minute
>3000V Between Poles
OPERATING TEMPERATURE: -30°C to 85°C
Specification of rocker swith:rocker switch,mini rocker switch,electrical switch.Rated working voltage and current: 3A-6A-15A 250VContact Resistance: ≤0.02ΩWithstand voltage: 1500VacInsulation Resistance: ≥1000MΩ
