Double Door Steam Sterilizer:

DEscriptION:

• The sterilizer is based on the principle that microbiological action of saturated steam at elevated temp is rapid and thorough. All models work on downward displacement of air principle which is most economical method of obtaining for all types of bulk sterilization which  Construction Robust and rugged all weld construction which is leak proof unlike riveted construction.
•  Inner chamber is made of thick plate of Mild Steel of non magnetic stainless steel of 304or 316 quality anare commonly needed in Medical, Agricultural and Pharmaceutical institute Suitable for sterilizing hospital dressings, linen, rubber plastic goods, surgical instruments, glasswares and utensils etc.d jacket is made out of rolled steel. Sterilizers will have single door made out of rolled steel lined with S.S. sheet on both sides. All the sterilizers are hydraulically tested to withstand 2.5 times the working pressure.
• The steam jacket is lined on the outer side with asbestos sheet or glass wool which prevents heat losses due to radiation and is covered by strong rolled steel sheet duly painted. Boiler Made of thick stainless steel plate suitably located under the sterilizer. High grade flanged type heating elements are fitted from front side for easy replacement or repair. Fitted with water gauge glass for water level, safety valve, water inlet and drain valves.
•  It is also provided with Low Water Level cut off device. This device protects the heater in the generator from burning out dry. The steam pressure in the boiler is indicated on an individual pressure gauge. Safety Lock for Door Every horizontal rectangular sterilizer is fitted with SELF LOCKING SAFETY DOOR which cannot be opened when the chamber is under pressure.
• The clutch mechanism automatically disengages the threads of the radial locking system for precluding any eventuality of accident when the chamber is under pressure. A heat resistant Neoprene Rubber gasket ensure steam tight fitting. Pressure Control Electrically operated Dan Foss (Pressure Control Device) is incorporated in all electrically operated sterilizers.
• It economizes power consumption and limits the use of release valve which would frequently blow steam into the room. It cuts off the power supply to heaters when the set pressure is achieved and re energizes heaters when pressure falls down.
• Sterilization Complete sterilizing cycle is controlled from one point with the help of Multi port valve fitted at front top. Two speeds of exhaust are available for evacuating. The Chamber Two separate valves provided for evacuating air and steam from inner chamber and jacket as and when desired. A steam trap is fitted in the chamber discharge line to eliminate the condensate automatically. Switch Box Houses the Pressure control switch, Main switch, Pilot lamps, relays etc. and mounted on the stand of the sterilizer for easy operation.
• Esteem Industries Inc. holds the right to updat the prices after 120 days.
• Also we will make this prodcut accroding to your reuirement.

1. Esteem Industries Inc., incepted in the year 1984. It was the vision of Mahendra Tandon and Late. Mrs. Rachna Tandon. The slogan of MRV (Morality, Reliability and Vision) was the birth child of late Mrs. Rachna Tandon. Since then it has been offering state-of-the-art products in the able leadership of Mahendra Tandon and equal hand of his son Vipul Tandon in ever expanding field of instrumental analysis.
2. We are the organization that deals in Manufacturing Exporting & importing the laboratory, medical, Surgical & Scientific laboratory instruments that meet the quality standards of quality assurance laboratories and Research & Development establishments. We take great honor to inform you that we are ISO 9000/9001/9004/19011:2000 Organization and have DGS&D Registration for Autoclaves & Sterilizers of various types.
3. We are in close association with numerous esteemed, medical colleges, hospitals, medicine manufacturing companies & Research laboratories. We are also manufacturing testing machines for testing of raw material by industries.
4. We produce our instruments out of the best raw material & under the supervision of most experienced, qualified Technicians & skilled craftsmen. Our objective is to acquire challenging position in globalized trade as innovative leader that demand the full utilization of our professional skill and experience. We welcome importers and distributors to partner with us. We are available for future communication and inquiries at your convenience and we look forward for having association with you.
