製品情報
原産地: | 中国(本土) | 銘柄: | LIB業界 | モデル番号: | 一定の温度湿度チャンバー | 使用法: | 産業 | 理論: | 温度調節器 | 正確さ: | 0.5イン℃± | 温度範囲: | 0℃~+150イン℃ | 温度範囲: | 0℃~+150イン℃ | 湿度範囲: | 20%〜98%rh | 温度変動: | 0.5イン℃± | 温度偏差: | 2.0イン℃± | 内装材: | sus304ステンレス鋼 | コントローラ: | プログラマブルカラータッチ- キータイプtemi880 | センサー: | 白金抵抗ptrpt100Ω/mv | 冷却システム: | フレンチテカムセコンプレッサー | 認証: | Ce/i so | キーワード: | 温湿度試験計器 |
包装
包装: | 標準的な輸出木製ケース |
仕様
温湿度試験楽器1.製造所2.3年間の保証3.20日配達4.経験8年
Temperature Humidity Test Instrument
Temperature Humidity Test Instrument Application
Temperature Humidity Test Instrument is widely used in the temperature variation tests,
cold resistance tests and storage with low-temperature in the fields of aerospace, aviation, electronics, instrument, electric products, materials, parts and components and equipment
to analyze and evaluate the property and performance of the samples under the simulated conditions.
Product Description
Temperature Humidity Test Instrument Specification
Model | TH-100 | TH-225 | TH-500 | TH-800 | TH-1000 |
Workroom dimensions(cm) | 45*45*50 | 50*60*75 | 80*70*90 | 80*100*100 | 100*100*100 |
Exterior dimensions(cm) | 105*88*144 | 105*102*200 | 132*132*217 | 147*152*231.5 | 167*152*231.5 |
Technical structure | |||||
Temperature range | -20~+150 | ||||
Low type | : -40 :-60 : -70 | ||||
Humidity range | 20% ~ 98% RH | ||||
Temperature fluctuations | ± 0.5 | ||||
Temperature deviation | ± 2.0 | ||||
Humidity deviation | ± 2.5% RH | ||||
Heating rate | RT ~ + 150 more than 40 minutes (about 3 / min) | ||||
Cooling rate | RT ~ - 40 more than 60 minutes (about 1 / min) | ||||
Control system | |||||
Controller | Programmable color touch-screen controller TEMI880 | ||||
Sensor | PTR Platinum Resistance PT100Ω/MV | ||||
Heating system | Independent Nichrome electronic heating system | ||||
Cooling system | French TECUMSEH compressor | ||||
Humidification system | External isolation, stainless steel surface evaporation humidifier | ||||
Dehumidification system | Evaporator | ||||
Water supply system | automatic control, water saving and power reducing | ||||
Circulatory system | Cold resistance and low noise centrifugal wind wheel | ||||
Material | |||||
Exterior material | Steel Plate with coating | ||||
Interior material | SUS304 stainless steel | ||||
Insulation window | Double thermostability silicone rubber sealing | ||||
Standard configuration | 1 Cable hole (Φ 50,) cover, 2 sets of shelf, 2 protector tubes, 1 overflow water tube,1 copy of operating specification | ||||
Timing Function | 0.1~999.9 (S,M,H) settable | ||||
Power Supply | AC380V 50HZ Three-phase five little system | ||||
Ambient Temperature | 5~+30 ≤85% RH | ||||
Standard | GB/T2423.1-2001; GB/T2423.2-2001 |
Temperature Humidity Test Instrument Structure Pictures
Temperature Humidity Test Instrument Picture Showing
Temperature Humidity Test Instrument Controller
TEMI880 Programmble touch-screen type : It can make programble and do cycle test
Temperature Humidity Test Instrument Test Holder
Material : SUS304 Stainless Steel (Adjustable)
src="http://g03.s.alicdn.com/kf/HTB1uHRLGXXXXXayXFXXq6xXFXXXu/220014134/HTB1uHRLGXXXXXayXFXXq6xXFXXXu.jpg"
Temperature Humidity Test Instrument PC link
(RS 285/232 LAN Connection Make sure chamber can be remoted control )
Temperature Humidity Test Instrument Power Supply
(AC380V+/-10 50Hz+/-10 Three-phase five little system)
Temperature Humidity Test Instrument Picture Showing
Packaging & Shipping
Temperature Humidity Test Instrument Packaging
Our Services
LIB Industry Warranty (Three Years)
All of our test chambers has three year warranty period. If the equipment is under the ordinary usage and arise any hardware problem which caused by product itself, rather than human error, we will offer the repair to you.
* Firstly, we can provide the spare parts with you. And also provide the solution about the trouble of the products.
* Secondly, Please send back the apparatus, which will be repaired by our company.
* Lastly, we would like to appoint our technical engineer to your company to repair the apparatus.
