を満たすように設計され、 ユーザの要件を小さなバッチプロセスを希望する閉のアンプルを未然に防ぐ洗浄するための必要性

The Adelphi OC Machine machine has been designed in response to the demand from small scale production and R&D laboratories wher closed ampoules are used to obviate the need for internal washing.

A flame of mixed gas and oxygen is applied to melt the glass of the closed ampoule. ‘Safety First’ flash back arresters are fitted to the gas inlets and needle valves control the settings.

The ampoules are placed into a manually operated spring loaded chuck and a flame is brought to bear on the top of the ampoule. As the flame approaches the glass an electric switch is thrown and the chuck rotates and when the opening station is in use the ampoule is opened with the flame. The ampoules can then be filled using an Adelphi Peristaltic Pump and Filling Jig.

When closing the gripper jaws are placed onto the ampoule neck and the flame operated. As the glass becomes plastic the counter weight pulling on the jaws draws off the ampoule neck and a perfect rounded finish is achieved with very little practice. The drawn off tip is dropped into a detachable box at the side of the machine to cool before disposal.

The sealing process is quick, regular in height and equivalent to that obtained from an automatic machine.

Although specially designed to open and close closed type ampoules this versatile machine will also handle open type ampoules after washing.

A 110v 60Hz version can be made to order.
