製品情報
| 条件: | 新しい | タイプ: | 円筒研削盤 | CNCまたはない: | 正常 | 最高。 粉砕の直径: | 580ミリメートル | 最高。 粉砕の長さ: | 160018002000 | 原産地: | 中国(本土) | 銘柄: | dlchem | モデル番号: | mq8260a | 電圧: | 220v | 力(W): | 9.82kw | 次元(L*W*H): | 4166x2037x1584mm | 重量: | 6000キログラム |
包装
| 包装: | 木製ケース |
仕様
また、 供給するmq8260aクランクシャフト研削盤: クランクシャフト研削盤mq8260amq8260cm8312amq8240
mq8260aクランクシャフト研削盤
特徴:
、。Three different work speeds are obtainable by making use of the belts in the workhead。
B。 One word type chucks are used in the headstock and tailstock。
C。 Friction coupling is used in the headstock transmission chain for its easy adjustment。
D。 Table traverse is operated either by hand or by power。
E。 Wheelhead rapid approach and withdrawal is effected through hydraulic means。
F 。The wheel spindle being of 80mm in diameter has good rigidity and strength。
G。 Use is made of roller ways for wheelhead movement。
H。 The bed ways and wheelhead are lubricated in an automatic cycle by means of the oil pump.
Main specifications:
モデル | mq8260ax16 | Mq8260ax 18 | mq8260ax20 | ||
最大。 work diameter ・回; max。 length | ・φ; 580・回; 1600 mm | ・φ; 580・回; 1800 mm | ・φ; 580・回; 2000 mm | ||
容量 | 最大。 swing over table | 580 mm | |||
Work diameter ground | ・φ; 30・回; 100 mm | ・φ; 50・回; 120 mm | |||
Throw of crankshaft | 110 mm | 120 mm | |||
最大。 work length ground in 3 jaw chuck | 1400 mm | 1600 mm | 1800 mm | ||
最大。 work length ground between centres | 1600 mm | 1800 mm | 2000 mm | ||
最大。 work weight | 120 kg | 150 kg | |||
ヘッドストック | Centre height | 300 mm | |||
Work speed ( rpm) | 25、 45、 95 | 25、 45、 65、 100 | |||
砥石台 | 最大。 cross movement | 185 mm | |||
Wheelhead rapid approach ・ withdrawal | 100 mm | ||||
Wheelhead feed per turn of cross feed handwheel | 1 mm | ||||
Wheel feed per grad of cross feed handwheel | 0.005 mm | ||||
Grinding wheel | Wheel spindle speed | 740、 890 rpm | |||
Wheel peripheral speed | 25.6 ・ndashする; 35 m/sec | ||||
Wheel size | ・φ; 90032x・φ; 305 mm | ||||
テーブル | Table traverse per turn of handwheel coarst | 5.88 mm | |||
Table traverse per turn of handwheel fine | 1.68 mm | ||||
Table swivel ( taper18/100) | 5・度; | ||||
Table swivel per grad of scale ( taper 1:50) | 10・度; | ||||
Overall capacity of motor | 9.82 kw | 11.2 kw | |||
Overall dimension ( 長さx幅x高) ( mm) | 4166x2037x1584 | 49002037x1584 | |||
重量 | 6000 kg | 6200 kg | 7000 kg | ||
作業 | Ovality (new standard | 0.005 | |||
円筒度 | 0.01 |
|
| ||
Roughness ra | 0.21 | ||||
また、 供給する:クランクシャフト研削machine mq8260amq8260c m8312amq8240
