製品情報
原産地: 日本 | 銘柄: サンクス | モデル番号: Ex-23-pn |
使用法: 位置センサー | 理論: 光学センサー | 出力: デジタルセンサー |
センサータイプ: アンプ建て- センサー | センサーの範囲: 2m | 電源電圧: 12-24vdc |
出力: /npnpnp出力 | 応答時間: 0.5ms以下 | 保護: ip67 |
ケーブルの長さ: 2m | 周囲温度: に- 30+70℃ | 材料: pbtエンクロージャ |
認証: cerohs指令ul |
包装
包装: パッケージ: 標準カートン重量: 45g約。 |
仕様
パナソニック超コンパクトex-23光電の光センサーアンプex-23-pn建て- センサー
Product Description
PanasonicAmplifier Built-in sensor EX-23 Ultra compact photoelectric light sensor EX-23-PN
Ultra-Compact Photoelectric Sensor
Amplifier Built-in sensor
The EX series of photoelectric sensors is a wide-ranging lineup of 116 different models.
Whatever your application entails, Panasonic has covered it with this series.
Built to IP-67 standards, the Ex series is designed for the most demanding environments.
There are also models that are specifically design for resistance to oil, coolant, or ethanol.
Couple this with high electrical noise resistance and a built in interference prevention function,
and you have one of the most robust sensors on the market.
model | Sunx EX-23-PN |
Sensor type | Thru-beam photoelectric sensor |
Sensing range | 2m |
Sensing object | ∅3mm or more transparent |
Supply voltage | 12 to 24VDC±10% |
Output | NPN/PNP output |
Output operation | Switchable either Light-ON or Dark-ON |
Response time | 0.5ms or less |
size | 10.5mm*8.2mm*19mm |
Protection | IP 67 |
Model Name; Type
EX-21A; Thrubeam, NPN ,Light-On ,
EX-21A-PN ; Thrubeam, PNP Light-On
EX-21B; Thrubeam, NPN,Dark-on
EX-21B-PN; Thrubeam, PNP, Dark-on
EX-23; Thrubeam,NPN,Switchable either Light-on or Dark -on
EX-23-PN ; Thrubeam, PNP,Switchable either Light-on or Dark -on
EX-29A ; Retroreflective, NPN ,Light-On
EX-29A-PN; Retroreflective, PNP ,Light-On
EX-29B; Retroreflective, NPN ,Dark-On
EX-29B-PN; Retroreflective, PNP ,Dark-On
EX-22A;Diffuse refiective, NPN ,Light-On
EX-22A-PN ;Diffuse reflective, PNP ,Light-On
EX-22B;Diffuse reflective, NPN ,Dark-On
EX-22B-PN ;Diffuse reflective, NPN ,Dark-On
EX-24A; Convergent reflective, NPN ,Light-On
EX-24A-PN; Convergent reflective, PNP ,Light-On
EX-24B; Convergent reflective, NPN ,Dark-On
EX-24B-PN; Convergent reflective, PNP ,Dark-On
EX-26A; Convergent reflective, NPN ,Light-On
EX-26A-PN; Convergent reflective, PNP ,Light-On
EX-26B; Convergent reflective, NPN ,Dark-On
EX-26B-PN; Convergent reflective, PNP ,Dark-On
EX-28A; Narrow-view reflective, NPN ,Light-On
EX-28A-PN; Narrow-view reflective, PNP ,Light-On
EX-28B; Narrow-view reflective, NPN ,Dark-On
EX-28B-PN; Narrow-view reflective, PNP ,Dark-On
