• ptfeオープンメッシュファイバーグラスコーティングされたファブリック長期間使用食品殺菌装置
    商品番号: 8720422
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    製品情報

    条件: 新しい 原産地: 中国(本土) 銘柄: yingxing
    モデル番号: w3008 使用法: フルーツ及び野菜 タイプ: マイクロウェーブ
    提供される売り上げ後のサービス: 利用できる海外第三者サポート ptfeコーティングされたオープンメッシュコンベアベルト: 4*4

    包装

    包装: ボックス

    仕様

    1.耐熱2.良い品質3.最もよい価格4.、 時間内にdelieveryの

    PTFE fiberglass open mesh conveyor belt




    Features Of PTFE conveyor belts:



    1.       High temperature resistance—It Can continuously work under-140 to 320°C,max resist high temperature up to 360°C.

    2.       Permeability—It can avoid wasting heat and improve drying efficiency for it’s permeability.

    3.       Chemical resistance—It can resist all most of chemical medicines.

    4.       Non Stick—It can easily remove all kinds of adhesives such as resin, paint and chemical medicine, easy to clean.

    5.       Good flex fatigue resistance—It has high tensile strength and excellent flex fatigue resistance. It’s better for small wheels.



    Applications:

    1.       Drying machine for non-woven textile, textile printing, silk-prnting and dyeing machine.

    2.       Shrinking machine for garment fabric, high-frequency and UV dryer.

    3.       Conveyer belt for hot-air dryer, various of food baking, quick-frozen machines.

    4.       Oiling machine for paper glazing and waxing, plant engineering.

    5.       Seperating sheet for hardboard production etc.



    Item No

    Mesh Size

    Material

    Thickness

    Weight

    Temp Resistance

    MaxWidth

    Tensile Strngth

    YX3001

    1x1mm

    fiberglass

    0.5mm

    370g/m²

    -140to320°C

    4000mm

    310/290N/cm

    YX3002

    2x2mm

    fiberglass

    0.7mm

    450g/m²

    -140to320°C

    4000mm

    350/310N/cm

    YX3003

    4x4mm

    fiberglass

    1.0mm

    400g/m²

    -140to320°C

    4000mm

    390/320N/cm

    YX3004

    4x4mm

    fiberglass

    1.0mm

    450g/m²

    -140to320°C

    4000mm

    390/320N/cm

    YX3007

    4x4mm

    kevlar &fiberglass

    1.2mm

    600g/m²

    -140to320°C

    4000mm

    895/370N/cm

    YX3008

    4x4mm

    fiberglass

    1.0mm

    500g/m²

    -140to320°C

    4000mm

    395/370N/cm

    YX3010

    4x4mm

    kevlar

    1.0mm

    500g/m²

    -140to320°C

    4000mm

    900/600N/cm

    YX3012

    4x4mm

    fiberglass

    1.0mm

    550g/m²

    -140to320°C

    4000mm

    395/370N/cm

    YX3013

    1010mm

    fiberglass

    1.2mm

    450g/m²

    -140to320°C

    4000mm

    360/300N/cm

    YX3014

    0.5x1mm

    fiberglass

    0.5mm

    420g/m²

    -140to320°C

    4000mm

    310/290N/cm

    YX3015

    2x2.5mm

    fiberglass

    0.9mm

    600g/m²

    -140to320°C

    3000mm

    390/320N/cm
