製品情報
| ～に使う: 貨物 | ドライブの種類: モーターを備えられる | 変位: 151 - 200cc |
| ボディタイプ: 開いた | 証明: ccc | 銘柄: dongben |
| 原産地: 中国(本土) | モデル番号: Db200zh-5a | サイズ: 35001480x2000mm |
包装
| 包装: Ckd形態; 40" hq: 34単位20" gp: ご注文に応じて12台と要件 |
仕様
Cheap New Products Chongqing China Gasoline Three wheel Moto 1).200cc air cooling engine 2).good quality and competitive
| Chongqing Dongben Motor Manufacturing Co.,Ltd | ||
| Product Name | Cheap New Products Chongqing China Gasoline Three wheel Motorcycle With Simple Cabin | |
| FOB Price | 1,300.00USD--1,800.00 USD FOB [Chongqing,China] Port {INCOTERMS2000} | |
| Product Technical Specifications(General Information) | ||
| Part I Technical Design | Application | passengers/cargo Transport |
| Design Max Speed | ≥55 km/h | |
| Loading Capacity | 1000 kgs | |
| Unladen Kerb Weight | 398 kg | |
| Dimension(L*W*H) | 3500*1480*2000 mm | |
| Color | Red/Orange/Bule/Sliver/Other colors | |
| Track | 1120 mm | |
| Wheel base | 2670 mm | |
| Ground Clearance | 160 mm | |
| Brake Mode | Front&Back wheels;Drum | |
| Transmission Type | Shaft Drive | |
| Exhaust Pollution | Subject to National Standard | |
| Power | 10.5 Kw | |
| Cool Type | Air Cooled | |
| Fuel Type | Gasoline | |
| Fuel Tank Capacity | 12 L | |
| Part II Operation | Starting System | Electric/Kick |
| Transmission | 5 Forward &1 Reserse Gears | |
| Gearshift Control | Manual-Foot | |
| Clutch Method | Manual-Hand | |
| Brake Operate Mode | Manual-Hand or Foot | |
| Part III Engine Details | Engine Type | Single cylinder,4-stroke,air cooled |
| Bore Stroke | 62×57.5mm | |
| Fuel Type | Gasoline | |
| Rated Power&Rotating Speed | 10.5KW /8000rpm | |
| Max.Torgue/Rotating Speed | 11.5N.m,6500rpm | |
| Displacement(cc) | 150cc/175cc/200cc/250cc | |
| Ignition System | CDI | |
| Apply to | Motor tricycle | |
| Starter | Kick/Electric | |
| Part IV Packing | Transport | By Land/Sea/Other |
| Port Of Loading | Chongqing/Shanghai/Other ports of china | |
| Original Manufacturer | Dongben Motor Manufacturing Co.,Ltd/China | |
| Package | Protective Packaging | |
| Loading Capacity (CKD) | 12 units in 20"GP,34 Units in 40"HQ | |
| Delivery Time (from loading port) | 15-20 Days after receiving prepayment | |
| Please Note: | ||
| *All sizes are approximate,any other sizes are available according to customers' special requests. | ||
| *For more optional details, please contact Dongben Motor Manufacturing Co.,Ltd directly. | ||
| *Any details of the tricycle should subject to our final confirmation before ordering. | ||
