製品情報
| 原産地: 中国(本土) | 厚さ: 0.4～40mm | 幅: 1000 |
| 長さ: 2000 | 技術: 冷間圧延される | 等級: GR2 |
| 銘柄: TUTENG | 標準: ASTM B265 TP270C TP270H TP340C TP340H 6Al-4V(Gr5) | 表面: 洗練された研磨または酸 |
純チタン板(JIS1種,JIS2種)チタン合金
純チタン JIS1種・・・板 TP270
冷間圧延 TP340C
熱間圧延 TP340H
TUTENG China's Top Class Titanium, Nickel materials Manufacturer&Expoter.
Application
Medical, aviation, military, petrochemical engineering, metallurgy, salt-making, textile, sports etc.
1.Size
Thermal processing condition (R), Cold-work condition (Y), Annealed (M)
- Thickness: 0.3~60mm
- Width: 400~3600mm
- Length: 100~5600mm
2.Mechanical Properties
Annealed status in room-temperature (20°C)
- Tensile Strength: σb≥345Mpa(50Ksi)
- Permanent Elongation stress: σ0.2≥276Mpa(40Ksi)
- Elongation: δ4D≥20%
- Reduction of Area: Ψ≥30%
3.Chenical Constituent
| Ti | Al | V | Mo | Ni | Pd | Fe | C | N | H | O | Others |
| Balance | - | - | - | - | - | ≤0.30 | ≤0.08 | ≤0.03 | ≤0.01 | ≤0.25 | ≤0.40 |
4.Production Process
The main production process of titanium bar are Fmelting —> Forging —> Hot Rolling —> Cold Rolling —> Shearing —> Pickling —> Flattening
4.1 Fmelting
