製品情報
| 原産地: 中国(本土) | 銘柄: 7-24tracking | モデル番号: Mt-20 |
| メインフレームの電源を供給する: Dc9-36v | 湿度: 20-95% | tempを作業: -20â+75â〜 |
| 防水レベル: ip65 | 作業周波数gsm: 850/900/1800/1900mhzの | 建て- サイレン: 95デシベル |
| バックアップバッテリ: 600mah、 dc3.7v | Gsm/gpsアンテナ: 建て- | gpsモジュール: U- blox |
| I/o: デジタル出力と13デジタル使用可能な入力 | 使用法: 自動 |
包装
| 包装: White/ギフトボックス |
仕様
Gps腕時計トラッカーferrrarimt-20リモコン音声モニタリング、 自動警報の消費電力を節約でき
Ferrrari gpsmt-20腕時計トラッカー
| 1. 導入 |
Mt- 20 is a economic/waterproofed gsm/gprs/gps motor alarm kits and tracker。 it follows the simple and usable、 all built-i n design concept while give the user friendly and reliable experience。
This small unit equiped with quad bands gsm/gprs module、 hi- sensitivity gps receiver、 shocking sensor and 433/315mhz rf module。 the built-i n gsm/gps antennas significantly short the installation time、 built-i n siren with off/on programmable feature will bring u more options for security purpose。
Mt- 20 support both gps tracking and lac/cid( gsm network station code) tracking、 which brings u a idea solution with 7- 24 position fix with no blind area for locating your mobile objects。
It can work alone without any third party help、 but also could integreate to a monitoring center base by sms query or tcp connection query。
| 2. specfication・特徴 |
2.1 main features:
- sms/gprs data transmit
- small and compact size with built-i n buzzer、 gsm/gps antennas and moving sensor
- arm/disarm by remote controller and sms command
- moving sensor and buzzer activate and deactivate programmable
- periodically position report with self- customize time interval
- illegal door open、 engine on、 move alarm by sms and missed phone call alert to preset 4 registered phone nos。
- geo fence setup and breaking alert ( one geo zone available)
- over- speed limit and over alert
- remote vehicle engine starter enable and disable( engine immobilizer)
- wireless panic button on transmitter
- battery tamper alert
- system access password protection
- dual tracking technology: gps and lac/cid tracking
- remote voice listenで-
- auto moving alarm area activate and alert
- 1 digital output and 3 digital inputs available
- intelligent power saving technology especially for motorcycle design。
2.2 specifications:
- gsm work frequency: 850/900 /1800 /1900mhz
- gps( sirf iii chipset) : frequency: l1, 1575.42 mhz。 minimum signal tracked: - 159dbm
- working temp - 20・度; c ~ +75・度; c
- humidity: 20~95%
- gsm/gps antenna: builtで-
- built-i n siren: - 85デシベル
- remote control: working frequency: 315hz/433mhzの。
コード: 1527/2240 study
Working voltage: 12v ( 27a 12v dry battery)
Control distance: 20- 100m
- mainframe power supply: 9- 36v dc
- backup battery: lithium battery 600mah、 3.7v dc
- tracking accuracy: 510メートル-
- waterproof level: ip65
| 3. 応用範囲 |
- motorcycle、 motorbike
- cars、 vehicle、 truck、 bus
- boats
Mt-20設置図:
追跡アンドロイドスマートフォンアプリのスクリーンショット:
