ng>Specificationsng>

ng>FP-GV2.15.00
(Solar keymark ,SRCC)ng>

ng>FP-GV2.05
(Solar keymark , SRCC)ng>

ng>FP-GV2.0
(do not have Solar keymark , SRCC )ng>

Dimension LxWxH (mm)

2050*1050*95

2015*1015*76

2000*1000*80

2000*1000*80

Gross Area (m2 )

2.15

2.05

2.00

2.00

Absorber Area (m2 )

1.963

1.78

1.82

1.82

Number of covers

1

Cover material

Low iron, tempered glass

Cover Thickness(mm)

3.2

Cover Transmission

>91.7%

Weight

38Kg

41.5Kg

34Kg

34Kg

ng>Absorberng>

Material

Aluminium board

Surface Treatment

Sputtering (Germany imported Blue titanium absorber )

Black Chrome

Absorptivity

95±2%

93%

emissivity

5±2%

9-11%

Construction Type

Grid type

Header Material

Copper TP2

Header tuber size

∮22mm* 0.8mm

∮22mm* 0.6mm

Riser Material

Copper TP2/CA1220

Riser tuber size

∮8mm*0.75mm for FP-GV2.15 ∮8mm*0.6mm for FP-GV2.05 and FP-GV2.0

Work Pressure

0.75Mpa

Test pressure

1.2Mpa,keeps 5 minutes

ng>Whole collectorng>

Max power G=1000W/㎡ per collector

1.52kw

1.352kw

1.25kw

1.05kw

Thermal effiency

0.795

0.788

0.744

0.76

heat loss coefficient a1*

2.889 W/m².K

3.411W/m².K

4.05W/m².K

4.05W/m².K

heat loss coefficient a2*

0.026W/m².K

0.024W/m².K

0.03W/m².K

0.03W/m².K

Maximum stagnation temperature for ambient conditions of 1000W/m2 and 30°C

190.6°C

188.4°C

160°C

140°C

ng>Thermal Insulationng>

Insulation Material

Fiberglass

Insulation Thickness

     50mm

             30mm

       30mm

         30mm

Density

48kg/cube for FP-GV2.15.00-A and FP-GV2.05-01-A , 36kg/cube for FP-GV2.0

ng>Casingng>

frame

Aluminium alloy

Galvanized steel

Aluminium alloy

Aluminium alloy

frame Colour

silver or black

Back Plate

Aluminium plate

Galvanized steel

Galvanized steel

Galvanized steel

Sealing Gasket

EPDM

ng>Approved by Solar-keymark, SRCC, CE, ISO9001,CCC,etc.ng>ng>ng>
