製品情報
原産地: 中国(本土) | 銘柄: xianghe | モデル番号: 10-50-20 |
色: 白い |
包装
包装: また、 ダンボール箱に梱包polybayまたはあなたの要求に応じてパックすることができ |
仕様
ライニング: ポリ塩化ビニールゴム製PUのジャケット: 高い粘着性ポリエステルヤーンか繊維の最大長: 120m WP: 4-120ba
指定
- Lining: PVC/ Rubber/ PU
- Jacket: high tenacity polyester yarn or fiber
1) PVC/ Rubber/ PU Lining
2) The jacket of fire hose is wove by high intensity of polyester filament or polyester short-fiber ( twill/plain weave)
3) There are special adhesive ( solid or liquid) between the jacket and the hose. the hose is soft and highly polishedのreduce the flow resistance
4) Thinner and more soft、 lighter and more convenient to use.
5) High pressure resistanceの low temperature resistance、 anti-corrosion. aging resistance.wear-resisting
6) We can provide different color lining: blue、 transparent black etc or according to your requirement
7) We can provide length and working pressure: according to your requirement
直径 (Inch/mm) | Working Pressure (MPa/BAR/PSI) | Testing Pressure (MPa/BAR/PSI) | Bursting Pressure (MPa/BAR/PSI) | 長さ (M/FEET) |
1 25 | 1.0/10/150 1.3/13/195 1.6/16/240 2.0/20/300 |
1.5/15/220 2.0/20/300 2.4/24/360 3.0/30/450
| 3.0/30/450 3.9/39/580 4.8/48/720 6.0/60/900 | 10 15/50 20 25 30/100
|
1-1/2 40 | ||||
2 50 | ||||
2-1/2 65 | ||||
3 80 | ||||
3-1/2 90 | ||||
4 100 | ||||
4-1/2 115 | ||||
5 125 | ||||
5-1/2 140 | ||||
6 150 |
