• テキスタイル開放幅コンパク
    商品番号: 1845033
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    製品情報

    条件: 新しい 自動等級: 自動 原産地: 中国(本土)
    銘柄: アジアスター モデル番号: yxls2400 電圧: 220v
    力(W): 100キロワット 次元(L*W*H): 40000mmx5100mmx2000mm 重量: 15トン
    証明: 中国の 保証: 1年間 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため
    グレー:

    包装

    包装: プラスチック

    仕様

    このオープン幅コンパクマシンはすべてに使用の天然繊維の。 水収縮率が5%以下を。

    マシンの使い方を:



    このオープン幅に適していコンパクmahcineはプレ- 縮小のオープン幅の天然繊維、 綿のような、 草、 とウール。 水は、 生地の収縮5%未満です。



    主な技術パラメータ:



    Chain working pattern :  chains circulation horizontal rotary

    Compacting pattern :    thickness 20- 21mmnomex felt

    Chains pattern:     pitch 60mm、 stainless steel chains。

    Rail pattern  stainless steel rail、 graphite strip、 non oil lubrication

    Machine standard power:  380v(& plusmn; 5%) 50hz3ph

    Control power:   220v、 24v

    Applicable steam specification:  36キロ-/cm・sup2; saturated steam

    Steam comsumption :  100~150kg/hour

    Applicable compressed air specification:  0.3- 0.6mpa compressed airwithout moisture

    Maximum temperature of the dryer cylinder:  190・度; c

    Applicable heat sourch    a。  circulation thermal oil

                                           b。  electric heated thermal oil

                                            c。  steam

    Circulation oil consumption:  3000040000- kcal/ h( 0.125- 0.2gj)

    Electric heated thermal oil consumption:   25- 54kw

    Steam roller consumption:  100- 150kg/h

    Main chain driven pattern: right and left chains drive seperately

    Felt maximum working width: 2600ミリメートル

    Pin plate maximum working width: 2800mm

    Width control pattern:   front and back drive seperately

    Machincial speed :    5~35m/min

    Power of some parts:   gluming、 切断、 sucking device   6.74  kw( オプション)

    Pneumatic edge spreader    3kw

    Driven device    25   kw

    Machine dimension( max)   l=15000  W=2570+working width H=2800

    Machine weight:  ab0ut 12tons

    Machine colour:   jewelry blue + crystal white



    マシンの利点:



    インフラ-red centering infeed device、  correct the fabrics movement path  自動的に(shanghai brand)

    Equip weft correct adjusting roller、  cooperate with the stenter fra-me pin plate、  with a different speed to correct the fabrics weft。

    Pneumatic edge spreader(teeth spreader is optional) to flat the curled edges.

    fAr infra- red auto edge detector and tracing system made in shanghai、  which can guarantee the fabrics pin on correctly、  the width of the pin can be controlled in  Minimum .

    The wool brush wheel overfeed and pin on、  right side and left side are driven by the separately motor、  controlled by the inverter、  overfeeding rate is - 20%---+30%。

    The chain copies hercules of germany.

    The right and left stenting fra-mes are driven by the separately motor、  can movement with the little different speed、  cooperate with the weft straighter to correct the weft。

    In front of the stenter fra-me and felt compacting unit、  equip two steaming box made of stainless steel、  the stenter fra-me steaming box equips air curtain in front side to block off the steam  dissipation、  which can guarantee the edge detector works normally( not disturb by the steam)。

    Two pieces of thicken felt( 20mm)、 the felt is used to compacting and setting、  especially for open width fabrics、 material is du pont nomex。

    Drying cylinder 熱ed by Electric thermal oil ( steam is optional) intelligent control。  temperature tolerance is +_3・度; c.

    The fabrics output by plaiting mode。

    Equip synchrocontrol devices、  can harmonize the proportional speeds of each units automatically。

    Adjust the speed of the machine by inverter、  him operation system。  plc programme controlled。



    機械製図:

     テキスタイル開放幅コンパク問屋・仕入れ・卸・卸売り テキスタイル開放幅コンパク問屋・仕入れ・卸・卸売り テキスタイル開放幅コンパク問屋・仕入れ・卸・卸売り テキスタイル開放幅コンパク問屋・仕入れ・卸・卸売り テキスタイル開放幅コンパク
