| 原産地: | 中国(本土) | 銘柄: | 黄金の鹿 | モデル番号: | Psf+psz | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 特徴: | 真空ボックスを作る | 動作: | 全自動、 半- 自動、 マニュアル | plc: | ジーメンス | 材料: | 鉄骨構造、 ステンレス鋼 | 処理タイプ: | 発泡スチロールの箱シェーピング | 製品タイプ: | 箱を特色にした | 生産サイクル: | sec60から150 | 製品サイズ: | に応じて異なるタイプ | 色: | 白と青、 またはカスタマイズされた | 歴史: | 20年以上 |
包装
| 包装: | 木製のケースに、 プラスチック紙やフィルムで包ん、 等。 |
Automatic Expanded Polystyrene Decorative Cornice Machine
Product Introduction:
1 The machine is integrated with international advanced electronic original components with PLC and a Chinese touch screen displayer.
2 It works in two modes: normal feeding and pressure feeding of material, and the two modes can be switched as the structure and form of the mould. It is opitional for full automatic, semi-automatic and manual operating method.
3 The machine is driven by hydraulic pressure with a fast/slow differential system to ensure the precise time for mould opening and closing in an economized time and stable operation.
4 Various of heating methods can be optionally used as per the product form so as to ensure the product quality. A vacuum and negative pressure system can ensure a low water content, rapid shaping, and short drying period (or without drying).
Technical Parameter:
Item | Unit Model | PSZ120 | PSZ140 | PSZ175 | PSZ2000 |
Mould Size | Mm | 12001000 | 14001200 | 17501450 | 20001600 |
Finished Products Size | Mm | 1080900x330 | 13201090x330 | 16001290x330 | 17501400x330 |
Mould Opening Distance | Mm | 1400 | 1620 | 1620 | 1620 |
Steam Consumption | Kg/cycle | 7 | 9 | 10 | 11 |
Steam Pressure | Mpa | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
Cooling Air Consumption | Kg/cycle | 45-138 | 50-150 | 60-190 | 65-200 |
Compressed Air Consumption | m³/ cycle | 1.5 | 1.8 | 2 | 2.2 |
Compressed Air Pressure | Mpa | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
Vacuum Pump Air Suction Amount | m³/h | 165 | 230 | 280 | 280 |
Production Cycle | Sec | 60-150 | 60-150 | 60-150 | 60-150 |
Installed Power | Kw | 9.1 | 12.1 | 14.1 | 14.1 |
External Dimension | Mm | 46001850x3300 | 50002050x3700 | 50002400x4000 | 50002650x4150 |
Installed Weight | kg | 3200 | 4300 | 4850 | 5300 |
Work Flow Draft:
Please be free to contact with us if you are interested.
