Function and Features

1 Single drum former device. Crusher can take both treated and untreated fluff pulp.

2 Fluff pulp feeding is controlled by servo motor. Or air laid paper can be used instead of fluff pulp to produce high quality pads.

3 SAP feeding device. SAP is added mixed with fluff pulp and controlled by servo motor. If use air laid paper to instead of fluff pulp, then SAP feeding device can be used as spare device.

4 Tissue paper double sides feeding units. If use air laid paper to instead of fluff pulp, then tissue paper is unnecessary to use.

5 Net shape pressing device. Cylinder pressing.

6 Fluff core or air laid paper position adjusting device

7 Fluff core or air laid paper cutting device. Cylinder pressing.

8 Bottom film and top sheet materials feeding unit , Glue adding and fixing shape by pressing.

9 Pad vertical folding

10 Wastes rejection device

11 Pad crosswise folding

12 Auto-counting and arrange coming out. (The main machine can link with stakcer machine to do automatic packing .)

Technical Parameters

1 Model: JWC-CFD-SV

2 Designed speed: 250 M/Min

3 Real production Speed: 200 M/Min

4 Product size: L: (350-1500)mm x W(300-900)mm

5 Qualified rate: 99.99% (The rate is compared with qualified products with gross output products within7.5 hours)

6 Efficiency: ≥90%(The rate is compared real output with principle output within 7.5 hours)

7 Installed capacity: 200KW(Including hot melt system)

8 Practical capacity: 140KW(Including hot melt system)

9 Electric power supply: Three-phase & four-wire 380V/50HZ(Ground wire)

10 Electric wire: 3x95mm2+1x25mm2+1x16mm2

11 Air compressor: >0.6Mpa, 1.8m3/min

12 Weight: about 70T

13 Noise: <85dB(A)

14 Machine size: (25x8x4)M

15 Working size: (29x10x5)M

16 Container: 3x40HQ+1x20GP
