| 原産地: | 中国(本土) | 銘柄: | sany | モデル番号: | SRSC45C1 | 保証: | 1年 | 条件: | 新しい | 認証: | iso9001 | 次元(L*W*H): | 11000*4200*5400ミリメートル | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため |
包装
| 包装: | ヌードパッケージ |
Applicability:20GP,40 GP, 40HP
Max. Lift Height:15100mm
Service Weight :71000 kg
Item | Specification Data | |||
base Data mm | overall dimension(L×W×H) | 11200×4200 ×4850 | ||
Track | 6000 | |||
Wheel base- Front | 3033 | |||
Wheel base-Rear | 2600 | |||
Ground Clearance | 250 | |||
Min. Turning Radius(20’ GP) | 8000 | |||
Applicability | 20’GP, 40’ GP, 40’HP | |||
Item | Specification Data | |||
Lifting Capacity | First Row | Load distance1970 mm | 1-4 layer:45000kg;5th layer:43000kg | |
Second Row | Load distance3820 mm | 1-4 layer:31000kg;5th layer:30000kg | ||
Third Row | Load Distence6320 mm | 1-3 layer:15000kg;5th layer:14500kg | ||
Max. Lift Height | 15100mm | |||
Spreader | Brommar RSX40 | Rotation Angle:Left 195º Right 105º Shift distance:±800mm | ||
Lifting Speed | Unloaded :0.42m/s;loaded (70% rated load):0.25m/s | |||
Service Weight | 71000 kg | |||
Engine | Model :Volvo-TWD1240VE Type:6 cylinder 4 Stroke Diesel Engine Rated power:256kW Control Type:Electronic | |||
Transmission | DANA Clark Control Type:Manual /Automatic | |||
Driving Axle | KESSLER Max. Silence Load:1500kN ;Max. Danymic:1070kN(v=25km/h) | |||
Hydraulic System | PARKER variable displacement piston pumps and major steering valve | |||
Electric System | CAN main line communication | |||
Steering & Braking | Hydraulic ,double-function cylinder Brake:Front wet-disc brake Parking Brake:manual button,dried-disc brake,hydraulic operating, mechanical reposition | |||
Tyre | Model :18.00-25, layer 40 Pneumatic tyre(pressure 1Mpa) Number :Front 4 Rear2 | |||
Data in Traveling | Forward :unload –rated load 25km/h-21km/h Reverse :unload-rated load 25km/h-21km/h Gradient(2km/h):unload-rated load 34%-20% Max. Gradient:Unload-Rated Load 39%-32% Traction:360kN | |||
