| 原産地: | 中国(本土) | 銘柄: | JOC | モデル番号: | PRL12X2000/9 | タイプ: | 機械を転がし、水平にする | 使用: | シート | キーワード: | 版の圧延及び水平になる機械 |
包装
| 包装: | 木の場合 |
Specification:
Model | Min.plate thickness (mm) | Main motor power (kw) | Levelling precision (mm/m) | Yield limit (Mpa) |
PRL-803000/7 | 30 | 130 | 1 | 360 |
PRL-801500/7 | 25 | 75 | 1 | 345 |
PRL-701000/7 | 16 | 40 | 1 | 345 |
PRL-602500/7 | 16 | 30x3 | 2 |
|
PRL-602000/7 | 10 | 30x3 | 1 | 360 |
PRL-60200/7 | 10 | 4x4 | 1 | 360 |
PRL-503600/7 | 15 | 113 | 1 | 360 |
PRL-503000/7 | 10 | 106 | 1 | 400 |
PRL-502000/7 | 10 | 18.5x3 | 1 | 240 |
PRL-45x2450/9 | 6 | 176.5 | 1 | 1500 |
PRL-404000/7 | 8 | 113 | 1 | 360 |
PRL-401500/9 | 16 | 9x5 | 1.5 | 345 |
PRL-36x3000/7 | 10 | 22x4 | 1.5 | 360 |
PRL-32x2500/9 | 6 | 15x3+7.5x2 | 1 |
|
PRL-32x2000/9 | 6 | 22x4 | 1 | 360 |
PRL-303000/9 | 6 | 60 | 1 |
|
PRL-301500/9 | 6 | 60 | 1 | 450 |
PRL-25x2500/7 | 6 | 15x2+7.5x2 | 2 | 360 |
PRL-25x1500/11 | 5 | 60 | 1 | 360 |
PRL-203200/9 | 6 | 7.5x4+1.5x2 | 1 |
|
PRL-203000/15 | 4 | 22x8 | 1 | 450 |
PRL-202500/9 | 4 | 11x5+22x2 | 1 |
|
PRL-202000/11 | 6 | 15x6 | 1 | 360 |
PRL-202000/7 | 8 | 4x4 | 2 |
|
PRL-18x2500/9 | 5 | 110 | 1.5 | 1600 |
PRL-16x3200/11 | 4 | 11x2 | 1 |
|
PRL-16x1600/11 | 4 | 11x5 | 1 | 360 |
PRL-12x2500/11 | 4 | 51 | 2 | 360 |
PRL-12x2000/11 | 3 | 33 | 1 | 450 |
PRL-103000/7 | 3 | 3.7x4 | 2 |
|
PRL-101000/11 | 2.5 | 3.7x6 | 1 | 360 |
PRL-6x2000/13 | 1.5 | 17x2 | 1 | 400 |
PRL-6x1600/17 | 1.2 | 22x2 | 1 | 430 |
PRL-2x1200/17 | 0.8 | 7.5x4 | 1 |
|
Remark:
For the model PRL12X2000/9, 12 means Max. plate thickness; 2000 means Max. plate width of levelling, 9 means the quantity of rollers on this machine
