| 原産地: | 中国(本土) | 銘柄: | を福田 | モデル番号: | XDR5142GJBBRHDコンクリートミキサー車 | 排出の方法: | 自動 | 混合力: | 0.5KW | 給水モード: | ポンプ | 働きの繰返し周期: | 60 s | 容量の開拓: | 750l | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 輪郭次元: | 6660 × 2480 × 3450 | モーター力: | 5.5kw | 充満容量: | 800 | 条件: | 新しい | 混合のドラムの速度: | 35r/min |
包装
| 包装: | 1、添付部品やツールに置く標準輸出ボックス。 2、コンクリートミキサートラックは、洗浄すべきで覆われたワックス前配達。 |
Hello, here is roy.
First of all, I am a 7 years experience in sales professionals, a super sense of responsibility, willpower, self-confidence, but also insist on a sports and reading every day.
Secondly, because I have a life plan and experienced people, so I chose the manufacturers is China's most advanced manufacturers, our products guarantee the highest price.
Finally, I sincerely hope you will reply to my mail, because you are such good people and make friends is my pleasure.
We produce all kinds fire fighting truck,fuel tank truck,cement truck,water truck,ractor truck,dump truck,cleaning truck,high working truck,garbage trucks,chemical truck,trailer,wrecker truck , vehicle , wrecker , rescue , recovery vehicle , we also design for client if they have different request .
We export south America,SaudiArabia, Africa,Columbia,
Panama,Asia and more than 80 counties .
We have big factory , quick production time ,long time warranty .
Welcome you come to china and visit our factory . we can offer invitation letter in 15 working days .
Product Description
Vehicle parameters | ||||
Vehicle Model | XDR5142GJBBRHD | Vehicle Brand | Xindongri | |
Overall dimensions | 66602480X3450mm | Curb weight | 5960kg | |
Loading capacity | 5m3 |
|
| |
Manufacturer | Hubei Xindongri Special Automobile Manufacture Co.,Ltd | |||
Chassis parameters | |||||
Chassis model | BJ5142GJB-G1 | Chassis brand | FOTON | ||
Overall dimensions | 6045x23002600mm | Wheel base | 3600mm | ||
Front/rear wheel track | 1790/1725mm | Front/rear suspension | 1245/1200mm | ||
Approach/departure angle | 29/32° | Maximum speed | 80km/h | ||
Chassis Manufacturer | BEIQI FOTON MOTOR CO.,LTD | ||||
Cab | Configuration | D1900 a row and a half cab(with sleeping berth),allowable 3 passengers,with warm air,all English signs in car body, English instruction ,international general accessories,double front windshield,power switch | |||
Color | White,other color is optional | ||||
Engine | Model | YC4D130-33 | |||
Emission | Euro 2 | ||||
Type | 4 cylinders,in-line,verticle type,4-stroke,water-cooled,turbo inter-cooling,direct injection,diesel engine | ||||
Rated power | 130hp,rated power speed 2800rpm | ||||
Displacement | 4214ml | ||||
Max.torque | 420N.m | ||||
Bore x stroke | 108x115mm | ||||
Manufacturer | Guangxi Yuchai Machinery Group Co.,Ltd | ||||
Tire | Size | 8.25-20 Double Star nylon tire | |||
Number | 6+1 nos | ||||
Brake | Air brake | ||||
Clutch | φ330mm diaphragm spring clutch | ||||
Fuel tank | 150L fuel tank | ||||
Rear axle | 1090C rear axle | ||||
Drive form | 4X2 | ||||
Rated voltage | Camel brand,24V,DC | ||||
Transmissions | 5 speed forward 1 reverse | ||||
Steering device | Power assisted steering | ||||
Steering wheel | Right hand drive | ||||
selecive configuration | Steel wire tire,air conditioner | ||||
If there is a slight change in the chassis parameters above,please take the actual product as the standard | |||||
Concrete mixer truck structure parameters | |||
Loading capacity | 5m3 | Tank material | 16MnQ345 |
Reducer | Domestic | Hydraulic pump | Domestic |
Hydraulic motor | Domestic | Radiator | Domestic |
|
| Color and Logo | Optional |
Standard configuration | Less than 7m3:chassis,sub frame,16MnQ345 mixer tank,domestic reducer,hydraulic pump, hydraulic motor,radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder. More than 7m3:chassis,sub frame,16MnQ345 mixer tank,Germany ZF p5300 reducer, Germany REXROTH A4VTG90 hydraulic pump,German REXROTH AA2FM80 hydraulic motor, radiator: ZHENHUA,water tank,cleaning hose,feed port, discharge port,climbing ladder. | ||
Selective configuration | Emergency high pressure oil hose(4 pieces),12m emergency oil hose(Italy),water cannon,large tool box,electric water supplying system. | ||
MOQ,payment terms,delivery terms,price | |||||
MOQ | One unit | ||||
Payment terms | T/T 30% down payment, 70% balance after inspection before delivery | ||||
L/C is optional | |||||
Inspection | Buyer's agent or third party inspection agency,the cost is paid by the buyer | ||||
Delivery term | 20 days from down payment | ||||
documentation | Maintenance manual | ||||
User manual | |||||
Packing list | |||||
Commercial invoice | |||||
Certificate of origin is optional | |||||
Spare parts list for purchase is optional | |||||
Standard tools | With standard tools for chassis and concrete mixer truck structure | ||||
Packing | The main vehicle nude and covered with wax, attached parts and tools put into standard export box | ||||
Other requirements | Please fill in here | ||||
FOB | USD | ||||
CNF/CIF | USD | Shipment |
| ||
Because exchange rate and ocean freight may be changed in near future,so the price is only valid for 15 days. Please confirm the price again with our company before placing the order,thanks. | |||||
Packaging & Shipping
1, attached parts and tools put into standard export box.
2, concrete mixer truck will be cleaned and covered with wax before delivery.
3, concrete mixer truck will be covered by waterproof cloth at the departure port.
4,Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers’ requirements.
5,some small concrete mixer truck can be put into container according to its overall dimensions.
Company Information
Hubei Xindongri Special Automobile Manufacture Co.,Ltd is a professional cement mixer truck manufacturer in China. Supply ability of concrete mixer truck is 200 units per month. We have a perfect quality inspection system for cement mixer truck. welcome to our company to purchase the cement mixer truck.
FAQ
1, How to purchase the concrete mixer truck from your company?
You can choose the model from our website, also you can tell our sales manger your specific requirements and we will recommend the suitable model to you. After confirming the model and price, we can sign the contract.
2,How to ensure product quality?
Firstly,we passed the international quality system certification. Secondly, Alibaba Group has conducted field certification for our factory. Finally,You can entrust third party individuals or organizations to inspect our products before delivery.
3, How to visit your factory?
After you arriving at China, you can fly to Wuhan airport. Wuhan airport is located in Wuhan City, Hubei Province. Our driver will meet you at Wuhan airport and take you to our city by car.
