| 原産地: | 中国(本土) | 銘柄: | ajt | 力のタイプ: | 電気 | モデル番号: | ihp75 | 重量: | 650キログラム | 保証: | 12ヶ月 | 条件: | 新しい | 次元(L*W*H): | 1400*1100*1030mm | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 保証期間: | 12ヶ月 | 色: | あなたの条件として | タイプ: | Ihp- シリーズ |
包装
| 包装: | stantdar輸出パッキング |
Peristaltic pump system consists of three parts: peristaltic pump drives, peristalsis pump head, handle wriggle pump.It could be used for pumping the mortar, foam concrete machine etc.
The superiority of the peristaltic pump:
1, no pollution: fluid, only contact, don't handle the pump body contact,
2, high precision: repeat precision, stability, high precision, low shear force.
3 is conveying shear sensitive, erosion strong sex of fluid ideal tool, good sealing,
4: has good self-priming capacity, may idling, can prevent backflow .
5, simple maintenance: no valve and seals
6, has the same flow two-way transmission capacity; No liquid idle operation situation of any other part of the pump will not cause damage; Can produce up to 98% of the vacuum degree; No valve, mechanical seal and packing seal device, also have the leak and maintenance of produce factors; To easily in the conveying, liquid or gas mixture of liquid, allow the fluid with solid diameter tube top diameter to a 40%; May transport all with grinding, corrosion, oxygen sensitive materials and various characteristics such as food; only for the components needed to replac the hose, replac operation is extremely simple; In addition to the hose, conveying products not with any parts contact.
Technical data:
Model | IHP75 |
Rate power | 7.5kw |
Rate of flow | 15m3/h |
Rate pressure | 0.8Mpa |
Rotate speed | 42r/min |
Dimension(L*W*H) | 1400*1100*1030mm |
Working temperature | 0-60° |
Horizontal transport distance | 500m |
Vertical transport distance | 20m |
Hosepipe | 30m |
Weight | 650kgs |
