| 銘柄: | ROADSKY | モデル番号: | RS3 |
包装
| 包装: | 、エクスポートおよび海上- に値する特別なパッキング |
The equipment forms convex marking line through the micro-computer system, sensor system, air compressing system, driving system, etc. The regular trapezoid convex markings shape, convex height and convex space can meet different needs depend on the requirements of clients, and fully conform to the international vibrating and reflective standards, and with stronger deformation, abrasion and shock resistance .etc.
Main Technical Specifications
Size (L×W×H):1,350×800×1,050 mm
G.W.: 260 kg
Engine: HonDA GS5.5 HP four-stroke air-cooled gasoline Engine with liquefied gas starter.
Engine rated power: 4.9KW
Max Climbing Angle: 18°
Driving Speed: forward 0-6km/h
back off 0-4km/h.
Working pressure: 0.6Mpa
Working voltage: 6V,12V,24V
Cubage of paint tank: 60liter (110kg)
Cubage of glass beads bin: 12kg
Thickness of bottom line: 1.6-2.0mm
Marking width standard type: 150/200/300mm
Heating fuel: carry 10kg to 15kg liquefied petroleum gas with one gas tank
Exhausting speed of cylinder: 0.036m3/min.
Spreading width of glass bead dispenser: 100-200mm adjustable
Marking speed:>400 m/h
Convex Height: 3-8 mm
Convex spacing: 0-1000mm adjustable
Convex length: 0-1000mm adjustable
Convex width: 30mm with 150mm standard marking bucket; 35mm with 200mm standard marking bucket, three pieces of convex for standard marking bucket 150mm and 200mm.(the quantity and the width of convex can be manufactured according to clients’ requirement)
