| 原産地: | 中国(本土) | 銘柄: | aoyue | 条件: | 新しい | モデル番号: | aoyue833 | タイプ: | はんだ付けする場所 |
包装
| 包装: | 標準的な輸出カートン |
AOYUE Solder Station 220V AOYUE883 IR Table Preheater Reball Reflow Station PRODUCT
PRODUCT DEscriptION
310310 mm effective pre-heating area. Minimizes warping on larger sized boards.
1500 Watts Ultra-High power heating element. Significantly shortens time to reach desired working temperature.
Closed loop control. Sensor can be attached to the board for a more accurate temperature feedback.
Triple sensor system enables us to monitor both top and bottom board temperature while adjusting the internal heater temperature.
Multi-Point board holder. Secure fit for various board sizes and shapes. Effectively minimizes BGA balls shorting together due to board warping.
Programmable 6 segment reworking profile. Set and store the desired duration and temperature to ensure high success rate for repetitive reworks.
Pre-Heater is compatible with hot air or Infra-red style top heaters.
Compatible with Lead free solder, RoHS compliant, CE and ESD Safe equipment.
| Power Input | Available in 110V / 220V |
| Power | 1500W (maximum) |
| Dimension | 520(l) x 370(w) x100(h) mm |
| Temperature Setting | 50C - 400C(^maximum) |
| Heating Type | IR Heating |
| Effective Pre-Heating Area | 310mm x 310mm |
