| 原産地: | 中国(本土) | 銘柄: | boyuejia | モデル番号: | BYJ-L402 | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | 色: | 赤または他の色あたりクライアント要求 | 組成: | 鋼 | を制作パネルのサイズ(l *ワット* t): | 1500-3000mm * 600ミリメートル* (60,90、120,150,180ミリメートル) | ce、isoが承認: | はい | サービス: | エンジニア利用可能にサービス機械海外 | タイプ: | 垂直金型 | 出力: | 高 | メンテナンスコスト: | 低 | 利点: | 高出力壁パネル生産ライン | 保証: | ワン年 |
包装
| 包装: | 標準パッケージとセキュリティパッキング |
Precast concrete wall panel eps block molding machine
Description1)The wall panels that can be produced by different mold cars as below:
l Length: 2270mm
l Width: 610mm
l Thickness: 50mm,60mm,75mm,90mm,100mm for interior wall
120mm,150mm,180mm,200mm for exterior wall
2)Advantages:
- High production output of 200,000 sqm a year
- Automatic control & easy operation
- Advance newest system high efficiency
- Full automatic production system
- Unique raw materials measuring ,delivery and mixing system
- High production output&less workers*Environmental protection
- Long-term professional and all-round services
- Free training
Specification1)Automatic Mold Car
Vertical Traction-type (Automatic) Sandwich Panel Mold Car | |||||||
Item No. | 2270/2440/3000 | ||||||
Size (L*W*H) | 3180*380*3480 | ||||||
Weight | 2700kg/2900kg/3000kg | ||||||
Mobile Power (KW) | ------- | ||||||
Mobile Speed (Meter/Minute) | <60 | ||||||
Composition | Master | Chassis Assembly, Front Vertical Shelf, Back Vertical Shelf, Back Pressure Panel, Rod | |||||
Accessory | Partition Panel, Side Mold, Bottom Mold | ||||||
Product Information | Thickness | Width | Length | Quantity /unit | Area(m2/Unit) | ||
2270 | 2440 | 3000 | |||||
50mm | 610mm | 2270mm | 56 | 77.5 | 83.35 | 102.48 | |
60mm | 52 | 72.0 | 77.40 | 95.16 | |||
75mm | 46 | 63.7 | 68.47 | 84.18 | |||
90mm | 42 | 58.16 | 62.51 | 76.86 | |||
100mm | 40 | 55.39 | 59.54 | 73.2 | |||
120mm | 36 | 49.85 | 53.58 | 65.88 | |||
150mm | 24 | 33.23 | 35.72 | 43.92 | |||
180mm | 20 | 27.7 | 29.77 | 36.6 | |||
200mm | 18 | 24.9 | 26.80 | 32.94 | |||
Remark | Equipment sets for production line: 2units of 1.5KW windlass for mobile equipment, 2units of transition car for production transition, 1set air compressor for spraying release agent, pour table. | ||||||
Any questions, please feel free to contact us directly.
