| 原産地: | 中国(本土) | 銘柄: | zb | レンダリングの高さ: | 5メートル | モデル番号: | ZB800-4A | レンダリングの厚さ: | 25ミリメートル | 重量: | 150キログラム | 自動等級: | 自動 | 力(W): | 2.2kw | 保証: | 12ヶ月 | 条件: | 新しい | 認証: | iso 9001: 2000 | 次元(L*W*H): | 800*650*480ミリメートル | 提供される売り上げ後のサービス: | 提供される海外サービス無し |
包装
| 包装: | 木製ケース |
Wall Rendering Machine
General Introduction
We are a professional manufacturer of Wall Rendering Machine . ZB400-4A Wall Rendering Machine is the extended version of all our plastering machine. It gathers all the advantages: mini size, flexible operation, simple structure and light weight. Especially suitable for small rooms.
Main features:
- It is new machine instead of hand made in construction plastering area
- The capacity is as 15 professional plasterers.
- The quality is subject to international wall plastering standard
- Very easy and simple to operation
- Saving more than 20% raw material(cement and sand )
- It can plaster the wall automatically and go up and down automatically
- It can plaster one by one. The thickness of the ash can be adjusted
- Easy to move, without removing any parts of the machine
- It has large capacity hopper, you can put the ash/lime/gypsum in it onetime.
- Easy to operate. One or two person can operate.
- The quality is up to the international standard. Leakage protection device with high sensitivity, suitable for construction site safety and reliability.
Technical data
ZB800-4A Technical data | |
Plastering Height | 0-5meters |
Plastering Thickness | 2-25mm |
Plastering Width | 80cm |
Capacity | 450 square meters/8 hours |
Dimensions | 800×650×480mm |
Voltage/frequency | According to your demands |
Power supply | 2.2kw |
Weight | 150KG |
Surface | smooth |
Vibrator | 2 vibrators |
Juncture device | Yes |
Smoothing knife | Yes |
Perpendicularity degree | ≤2mm |
Level degree | ≤2mm |
Wall Rendering Machine VS Manual Work
Time Sheet
Step2 | Assemble machine | 120 seconds |
Step3 | Move the machine to the wall for rendering | 20 seconds |
Step4 | Adjust the vertical and horizontal level | 20 seconds |
Step5 | Load any kind of suitable mixture to tank | 30 seconds |
Step6 | Render one section 800 mm | 60 seconds* |
Remarks: * means the time of rendering up to 3 m height of wall with 800 mm width for one section
