GFRC Material:

Glass Fibre Reinforced Concrete (short for GFRC) is one of the most versatile building materials available to architects and engineers. Composed principally of cement, sand and special alkali resistant (AR) glass fibres, GFRC is a thin, high strength concrete with many applications in construction.

All the materials used are name brand materials and pass tests by authority. We hope we can be an example in the industry, and we are willing to create brilliant achievements in this field together with parties from the same trade.

Cement---Portland Cement in accord with ASTM C150

Fiberglass---Alkali resistant fiberglass with high zirconia content is designed for concrete use.  Minimum content of zirconia is 16%, 25-50mm in length, in accord with PCI-MNL-130

Silicon sand---washed and dried, clean and not adhere to each other. Meet requirements of GRCA standard: with maximum 1% of soluble salt, SiO2>96%, Cl- ion ≤600ppm, maximum 0.5% ignition loss. All find articles shall pass 1.2mm sieve. For 0.15mm sieve, pass rate shall not exceed 10%.

Cast-in---Shall meet requirements of ASTM A1011 or A1008. Yield strength shall comply with the requirement of minimum and maximum value.

Additive---Shall meet requirements of Type A, B, D, F and G in ASTM C494 or requirements of ASTM C260; meta Kaolin and other materials shall meet ASTM C618; Stains shall be stable under high temperature and alkali assistant, won’t affect curing and strength; colored paints and white paint shall meet ASTM C979; it’s ok to apply polymer curing agent instead of water in accord with PCI-MNL-130.

The features of GFRC

Thickness: Thin yet strong,only 12-20mm thick,much thinner than traditional precast concrete.

Lightweight : Weight only 20% of normal concrete,easy to handle and transport,fast installation,thus save time and cost.

Durable: Reinforced with glass-fiber and would not rust as steel,GFRC product has higher crack resistance.

Products proved to have the life cycle of normal concrete,minimize maintenance cost.

Versatility: Flexible in design,can replicate any shape including historic features.

Colour : It can be painted,to resemble stone,wood,metal or any design of surface finishing.

Moisture Resistant : GFRC will not rot,disintegrate or swell when expose to water,excellent for external cladding application.

Strength : Higher compressive and tensile strength,impact resistance.

Fire Resistance Performance: Made of minerals that would not burn and can provide fire protection to the materials that covers.

Environmental Friendly: Lightweight and durable,GFRC is designed to be long lasting.

Zhuhai Xinming Construction Material Co.,Ltd invested by Macau MeiCheong Group, is a pioneer of international castings of GRC, GRP,GRG and Marble Panel. With a factory covers 30000 square meter, it has been making amazing achievements since the past few years and receives a lot of praise.

Zhuhai Xinming Construction Material Co.,Ltd provides one-package service including project programming, design, drawing, mould making, production, QC, package & delivery and also installation. We can provide more active service since staff for each process are from the same management team.

Please visit our web-site www.chinagfrc.com or www.meicheong.com and contact us for any further information, we are more than happy to serve you.
