• デジタル電子ledスクリーン看板パネル-広告用スクリーン
    商品番号: 12331799
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    原産地: 中国(本土) 銘柄: ccy モデル番号: p6
    デジタル電子ledスクリーン看板: デジタル電子ledスクリーン看板 デジタル電子ledスクリーンパネル: デジタル電子スクリーン看板パネル

    包装

    包装: 梱包で木製ケースまたはフライトケース

    digital electronic led screen billboard panel

    -high brightness with high clear screen

    -long lfe and lower consumption

    -high viewing angle

    -gold after service





     p6 indoor led billboards(3IN1)

    Indoor full color series

    CCY-IR.-P6



    digital electronic led screen billboard panel parameters

    Product No.

    P4

    P6

    P7.62

    P10

    P12

    Physical pixel pitch

    4mm

    6mm

    7.62mm

    10mm

    12mm

    Physical pixels per sqm

    62500

    27777

    17222

    10000

    6944

        Pixel constitution

    1R1G1B

    1R1G1B

    1R1G1B

    1R1G1B

    1R1G1B

     Cabinet size

    512*512mm

    768*576mm

    976*732mm

    1280*960mm

    768*576mm

     Cabinet weight

    18kg

    30kg

    40kg

    56kg

    30kg

     Cabinet resolution

    128*128pixels

    128*96pixels

    128*96pixels

    128*96pixels

    64*48pixels

     Best viewing distance

    4m

    6m

    7.5m

    8m

    10m

    Max. power consumption

          1400W

    1100W

    700W

    800W

    750W

    Ave.power consumption

    350W

    2800W

    180W

    200W

    170W

    Brightness

    ≥2000CD/m2

    ≥1500CD/m2

    ≥1200CD/m2

    ≥1500CD/m2

    ≥1000CD/m2

       Driving method

    1/8scan constant current driving

    1/4scan constant current driving

     Best viewing angle

    Horizontal: ≥120°; Vertical: ≥120°

     frame frequency

    ≥60Hz/s

    Refresh rate

    ≥400Hz/s

    Color

                                     281 trillions

     Input voltage

                             AC 110 or AC220 V ±10% ,50 to 60Hz

    MTBF

     10,000 hours

    Life-span

    100,000 hours

        Ingress protection

     Front IP31

      Working environment

                       Temperature: -20°C-50°C; Humidity: 10%-90%RH
