| 原産地: | 中国(本土) | 銘柄: | KVSIO | モデル番号: | KVS-9202 |
包装
| 包装: | 泡泡、カートン、木の場合 |
Basic functions:
- Internet/information access
- Account inquiry & transfer
- Retail/ ordering/ payment
- Ticketing/photo/card printing
- Tel / transport card recharging
- Photos, ring tones download
- Product information release
Optional functions:
- Collection pay for utility bills, telephone/ broadband fees
- Foreign currency exchange, bonds and funds business
- Invoices printing, card issuing, multi-media input/output
- Personal authentication, attendance, change
Basic Configurations:
- Powerful Regular PC or Industrial PC
- 32, 42, 52 inch or above TFT LCD monitor
- 32, 42, 52 inch or above SAW/Infrared/Resistance/Capacity touch screen
- Manual insert or motorized card reader for magnetic/IC cards reading
- Rugged metal PC keyboard or metal Encrypted pin pad/EPP
- Thermal/dot matrix Receipt Printer, 60/80/112mm paper width optional, with auto cutter
- Multi-media Speakers
- OS Window XP2003( test or licensed version)
- All Steel made Enclosure(stainless steel, aluminum optional)
- Power costing or automobile paint
- LOGO&Color upon request
Optional Configurations:
Following components can be integrated into Kiosk upon specific application requirement.
- Cash Acceptor
- Cash Dispenser
- Coin Acceptor
- Coin Hopper
- Check Reader
- Passport Reader
- Fingerprint Reader
- Bar-code Scanner
- Card printer
- Card dispenser
- A4 laser/thermal printer
- Wireless connective (WIFI/GSM/GPRS)
- UPS
- Telephone
- Camera
- Motion Sensor
- Air conditioner
Reference Configurations:
| Components | Model No. | Detailed Discription | |||||
| Computer parts | PC Host | Motherboard: Intel H61 | |||||
| CPU:Intel duo core G620 | |||||||
| RAM:2GB; Hard Disk:80G 7200r | |||||||
| 1 RS-232 Ports;2 LTP;4 USB Ports,1 10/100M Net Port | |||||||
| Integrated Net Card, Sound Card, Video Card | |||||||
| Additional colorful video card | |||||||
| Computer case and power supply | |||||||
| Monitor(Top) | 19" LCD | Brightness: 300lumens/m2 | |||||
| Contrast: 450:1 | |||||||
| Response Time:5ms;Dot pitch: 0.297; | |||||||
| Max. resolution:1480×1024 | |||||||
| Monitor | 32" LCD | Brightness: 300lumens/m2 | |||||
| Contrast: 450:1 | |||||||
| Response Time:5ms;Dot pitch: 0.297; | |||||||
| Max. resolution:1480×1024 | |||||||
| Touch Screen | 19'' infrared | High Transparence, high precision and durability | |||||
| antirust,anti-acid,anti-dust | |||||||
| Thickness: 6mm, Max: 4096×4096 | |||||||
| Surface Hardness: Mohs' hardness rating of 7 | |||||||
| Force<100G; Response Time:20ms | |||||||
| Card Reader | CRT-284 | EMV certificated manual insert type credit card reader, USB port | |||||
| Receipt printer | Epson M-T532 | Thermal Printer;Automatic Paper Cutter; RS-232; Paper in Width:80mm; Speed:150mm/Second; Invoice Print; with Black Mark Sensor | |||||
| Speakers | Left and right bi-channel; amplified output; Multimedia speaker | ||||||
| Enclosure | KVS-9202 | Durable steel frame, Power coated; Slim and smart design; Easy to install and operate; Moistureproof,Antirust,Anti-acid,Anti-dust,Static free,Graphics on front of kiosk, color painting and LOGO printing upon request. | |||||
| OS Software | Microsoft Windows 7 Pro (Trial version), all hard drivers are available | ||||||
| Packing | Bubble Foam, Carton, Wooden Case | ||||||
