| 原産地: | 中国(本土) | 銘柄: | 深センervan | モデル番号: | l05g | 電池のタイプ: | パワー | 球根のタイプ: | LED | 指定: | ※26600/1200/1500mm | 材料: | Al+pc | 認証: | vderohs指令ultuv | 使用法: | 屋内使用 | 寸法: | 26*588mm/1198mm/1498mm | パワー: | 11ワット/20w/24w | led数量: | 108個/216pcs/240個 | pf: | >0.95 | 電力効率: | >0.90 | cri: | >80 | ルーメン: | 100lm/w | ランプホルダー/基地: | g13 | 入力電圧: | Ac100-2770v | ビーム角: | 120° |
包装
| 包装: | に1個ギフトボックス、 25pcs/インナーボックス、 カートンごとの50個600mm25pcs/インナーボックス: 73*24*24cm、 50pcs/カートンを測定: 74*48*26cm1200ミリメートル25pcs/インナーボックス: 133*24*24、 50pcs/カートンを測定: 135*48*26cm1500ミリメートル25pcs/innerbox: 163*24*24、 50pcs/カートンを測定: 165*48*26cm。 |
Description:
L05G is our hottest selling, most successful and most beautiful product, which is most popular
in the world market thanks to its unique design on the lockable rotating end caps and blue shining ring.
It is perfect choice for the replacement of all the traditional tubes.
Feature:
Lifespan: >50,000hrs
Up to 70% Energy Saving Consumption
High Brightness
Easy Installation
Ballast Bypassed/ Removed
Instant On
High Shock/Vibration Resistance
No Buzzing
Environmental-friendly and less hazardous without mercury
No Radio Frequency Interference
No Flickering
Fast Return on Investment
Technical Specifications:
1. Electrical Specifications:
L05G / 11W / 16*588MM / 108PCS / 1155lm±10%
L05G / 20W / 26*894MM / 216PCS / 2100lm±10%
L05G / 20W / 26*1198MM / 216PCS / 2100lm±10%
L05G / 24W / 26*1498MM / 240PCS / 2520lm±10%
Operation Temperature: | -20°C to 40°C |
Storage Temperature: | -40° to 85° |
Voltage: | 100-277v |
Frequency: | 60HZ-50HZ |
Power Factor: | >0.95 |
Power supply Efficiency: | 0.86 |
2. Photometric Specifications:
LED Luminous Efficiency: | Up to 100lm/w |
CRL: | Ra: >80 |
CCT: | Warm White 3000k |
daylight white 4000k | |
pure white 5500k | |
cold white 6500k |
3. Mechanical Specifications:
Beam Angle: 120°
Light-emitting surface: 230°
Isolated power supply
Latest lockable rotating end cap
Europe safety wired
Frosted or clear cover available on request
Weight: 588MM/210g, 1198mm/368.2g, 1498mm/443.8g
Can be placed in conventional T8 or T10 fluorescent brackets and replace fluorescent tubes
Installation:
.jpg)
