製品情報
原産地: 中国(本土) | 銘柄: cotek | モデル番号: Ctk-720c |
電圧: Ac90v-240v | キャッシュキャパシティ: 1-8m | フィード紙の幅: 360ミリメートル/720ミリメートル/870ミリメートルです/1100/1350ミリメートル |
カッター圧力: 50-990g | 切断幅: 300m/630ミリメートル/780ミリメートル/1000mm/1260mm | カッティング速度: 50-800mm/s |
ドライバー: /ステッピングサーボ | 切断幅: 限られたなし | リピートカッティング: <+- 0.1mm |
サイズ: 36cm*36cm*97cm | カッター: 高- スピードカーボン合金- スチールカッター |
包装
包装: プラスチックフィルム包装の内側と外側カートンケース/offerすべての12個用の木製パレット |
仕様
1,ce/i so/rohsサーボプロッタ2,10-990g、 50-1200mm/s3,高速、 高圧、 ノイズなし4,したレーザー光アイ
サーボプロッタ主な特徴:
1,ce/i so/rohs指令カッティングプロッタ
2,10-990g、 50-1200mm/s
3,1-8mメモリ
4,カッティングプロッタレーザーを用いた光アイ
説明:
1@・@cotek series cutting plotter adopts the control system with totally independent
Intellectual property、 totally solve the problem of the cutting length of the traditional
Cutting plotter is limited by the byte、 making the cutting length of the machine to reach
Over 100m。
2@・@: the strait line engine control pen totally solves the problem of the traditional ones
Easy to be destroyed and largely enlarge the cutting precision。 the driver can making
The use more convenient and use the international famous engraving software to output
engrave。
パラメータのカッティングプロッタ:
モデル | Ctk-360c | Ctk-720c | Ctk-870c | Ctk-1100c | Ctk-1350c |
最大用紙幅 | 360ミリメートル | 720ミリメートル | 870ミリメートルです | 1100ミリメートル | 1350ミリメートル |
最大切削幅 | 430ミリメートル( 12") | 630ミリメートル( 24") | 780ミリメートル( 30") | 1000mmの( 39") | 1260mm( 48") |
モーター | 元の輸入された高速ステッピングモータ | ||||
カット圧/speed | 10-990g / 50-1200mm/s | ||||
cartriage | 全体のアルミニウムcartriage内側、 インポートされたギヤ。 | ||||
機械的分解能 | 0.0254mm/step( 0.001」/ステップ) | ||||
特別な設定 | デュアルカッターホルダー、 デュアルストリップ | ||||
スタンド | はい、 すべてはスタンドが付属してbesidesctk-360c | ||||
インターフェイス/ems- メモリ | Usbシリアル・/4m | ||||
制御言語 | Dmpl/hpgl |
