| 原産地: | 中国(本土) | 銘柄: | topsky | モデル番号: | GYH25 | 測定範囲: | (0〜25) % | 測定誤差: | 未満± 3% | 応答時間: | 未満20 s | 入力電圧: | dc (9〜24) 12v | 出力信号: | (200〜1000) 60hz | デジタル信号: | 2400bps | 伝送距離: | 以上2キロメートル | アラームポイント: | 連続的に調整 | アラームモード: | 断続的なサウンド&ライト警報 | サウンドレベル: | 以上デシベル |
包装
| 包装: | 保護ボックス |
Specifications
Meter for o2 detecting, on-spot display, long-distance signal comunication,sound and light alarm,infrared remote adjusting
Application
This product forms a new generation intelligent oxygen sensors. With the standard signal output, it can working together with or various kinds of monitoring systems and breakers to continuously monitor the concentration of the Oxygen in an environment wher flammable and explosive mixed gases exist. It has the functions of long-distance communication,big output power for connection points, on spot display, sound & light alarming,infrared remote adjusting, and is easy to install and operate etc.
Technical Specification:
Item | Specification | |
Measuring Range | (0~25)% | |
Measuring Error |
less than ±3% | |
Response Time | Less than 20s | |
Input Voltage | DC(9~24)V | |
Output Signal | (200~1000)Hz | |
Digital Signal | 2400bps | |
Transmission Distance | More than 2km | |
Alarm Point | Continuously adjust | |
Alarm Mode | Intermittent sound & light alarm | |
Sound Level | More than 85dB | |
Explosion Protection | Exibd I | |
Working Life | More than 2years(electrochemistry) | |
Display Mode | 3-digital LED | |
Dimensions | 270×120×50mm | |
Weight | 1kg | |
Fittings | FYF5 Coal mine remote controller |
