Specification

camera

1. camera size:6mm

2.Camera case material: stainless steel house stainless steel 304

3. Camera glass material: sapphir glass

4. sensor size: 1/12 inch

5.Total Pixels: PAL: 720576    NTSC: 720480

6. view angle 60°

7. camera light: 4PCS white LEDS

8. waterproof: IP67

9.camerawork current: 100MA      camara power supply: DC 3.3V

10. LEDS ADJUASTABLE

11.Work temperature: -10°C-50°C

monitor

1. monitor size:  7inch  TFT color monitor

2. monitor Total Pixels:1440234

3. monitor power supply: DC 12V

4. osd language:  english

5. up, down  left, right adjustable

6. 16:9  4:3 model

7. sunshade includ

8. waterproof connector

9. Work temperature: -10°C-50°C

Cable wheel

Cable size:320MM(diameter)X110(h)

Wire material: fiberglass rod

Fiberglass length: 20M( standard)

Fiberglass diameter: 4.8MM

Fiberglass color: yellow

battery

Battey pype:   12V 4000MAH     rechargable li –ion battery(18650)

Used time:    7  hours

charger

input:  AC90-260V        output:  DC 12V    1000MA

Output cable length: 1.5M

DC plug diameter: 2.1MM

box

box material: fire protection

Box size:  48cm x 39cm x 19.5cm

Weight and cartoon size

net weight: 7.5KG

gross weight: 8.5KG

Single package size

Double package size
