| 原産地: | 中国(本土) | 銘柄: | 瑞麗 | ドライブの種類: | 空気 | 適用: | 他 | モデル番号: | Dcs-ton | 自動等級: | 自動 | 包装材料: | 他 | 包装タイプ: | 場合 | タイプ: | 充填機 | 条件: | 新しい | 力: | 3.5kw | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため | アプリケーション: | 食品 |
包装
| 包装: | 標準的な輸出plywoodenケース |
Suitable Materials:
All kinds of granular materials.
Advantage:
This scale is special for 500kg level quantitative packing function field. It can support up to 2000kg per bag and has some leading feed-in technology, which can use vibration to make bag solid.
Main Structures:
1.Auto dosing fill system(floor scale type)
2.Auto weighting balance
3.Electric control cabinet
4. Inflate bag function
5. Conveyor transportation
Flowing Process:
Manual bag placing-->Auto filling-->Auto weighing-->Auto Bag Discharge-->Bag transportation-->Next Round
Techmical Parameters:
| Precision | : +/-0.2% |
| Packing speed | : 5~ 30 bags per hour |
| Weighing scale | : 500kg~1000kg,1000kg~2000kgper bag, can be adjusted freely |
| Power Supply | : 220Va.c and 4N-380Va.c |
| Power Dissipation | :0.5-3.5kW |
| Compressed Air | : 0.4MPa~0.6MPa |
| Compressed Air Consume | : 1m3 per hour |
Special Customer Design:
This scale has stainless steel mode, which is used stainless steel to make scale. This mode is very suitable for the corrosive chemical material and food safety requirements material.
