| 原産地: | 中国(本土) | 銘柄: | dunli | モデル番号: | YWF4T-630 | 認証: | ccc、 ce、 rohs、 iso9001、 iso14001 |
包装
| 包装: | での梱包輸出木製パレットのための標準カートンまたは紙パレットの寸法を物流用カートンはそれぞれ異なっているとあなたのために必要な数量、 より多くの情報連絡plsは私たちのセールスエンジニア、 を供給すると私達はあなたのために最高のサービスと製品の高品質ファン |
1. Dunli YWF serial axial fan motors have been certified as compliant for CCC, CE, ROHS, ISO9001, ISO14001. It suits application with ventilation volume of 1,400~13,000m3/h, and can be widely used in refrigeration and warm ventilation industry.
2. Dunli axial fans with external rotor are featured with compact structure, small size, light weight, convenient installation, low noise, low start-up current, large torque and high efficiency.
3. The motors of Dunli axial fan can be divided into two types: Single-phase asynchronous capacitor-run motor, and three-phase asynchronous motor. The motors can work in environment with temperature from -30 to +50°. They are with protection class of IP54 and insulation class of B grade. With direct cooling, low temperature rise and thermal protector, the average service life of the motors is over 30,000 hours when working under condition of continuous rated load.
4. The rotor of dunli axial fan is balanced at two ends and the precision class is over G6.3. The rotor is featured with low vibration, smooth running and reliability.
