| Order No. | 920-2608 | 920-2612 |
| Max. swing diameter | over bed(mm) | 660(26") |
| over carriage(mm) | 420(17") |
| over gap(mm) | 870(34") |
| Max. truned diameter(mm) | 520(20-2/5") |
| Max. length of workipiece(mm) | 2000(80") | 3000(118") |
| Effective length in gap(mm) | 240(9") |
| Spindle | Spindle bore(mm) | 105(4") |
| Taper of bore | 113mm1:20 |
| Number of speeds | 12 |
| Spindle speed scope(r/min) | 36-1600 |
| Thread cutting | 22 Metric Threads | 1-14mm |
| 25 Inch Threads | 28-2 TPI. |
| 24 Diameter Pitch Threads | 56-4D.P |
| 18 Module Threads | 0.5-7mm |
| Range of feeds | Longitudinal(mm) | 0.063-2.52(0.023"-0.937) |
| Cross(mm) | 0.027-1.07(0.011"-0.404") |
| Rapid traverse | Longitudinal(m/min) | 4.5 |
| Cross(m/min) | 1.9 |
| Max. traver of top slide(mm) | 145(5-3/4") |
| Max. travel of cross slide(mm) | 310(12-3/32) |
| Max. size of tool(WxH)(mm) | 25x25(1"x1") |
| Tailstock sleeve | External diameter | 75(2-61/64") |
| Taper of bore | M.T.NO.5 |
| Max. traverse(mm) | 150(5-29/32") |
| Power of main motor(KW) | 7.5(10HP) |
| Overall dimensions(LxWxH)(mm) | 35001100x1450 | 45001100x1450 |
| Net weigh(kg) | 3000 | 3350 |
