• ねじ継手用射出成形機-モールド成型機
    商品番号: 10974760
    仕入れる商品へのお問い合わせについて、
    お電話の場合:スタッフに商品番号をお伝えください。
    商品の詳細

    電圧: カスタム 原産地: 中国(本土) 銘柄: longshun
    製品容量: 多数個 条件: 新しい モデル番号: Lsf-398
    重量: 16トン 力(W): 20キロワット 保証: 1年
    認証: iso9001、 sgs 次元(L*W*H): 7.3*2*2.2 提供される売り上げ後のサービス: 利用できるエンジニア機械類を海外に整備するため
    電圧: カスタム

    包装

    包装: 標準的なパッキング

    injection molding machine for screw fittings



    We are professional manufacturer of Injection Molding Machine, clamping  from 600 to 32000KN, weight from 68g to 40570g, different model for different production requirements, welcome contact us for more details and professional services.



    Specification of LSF-398;







    INJECTION UNIT



    Unit

    LSF-398

    A

    B

    C

    Screw Diameter

    Mm

    70

    75

    80

    Screw L/D Ratio

    L/D

    21.4

    20

    18.8

    Short Size

    Cm3

    1385

    1590

    1809

    Injection weight

    G

    1260

    1447

    1646

    Injection Rate

    g/s

    310

    356

    405

    Plasticizing capacity

    g/s

    60

    65

    70

    Injection Pressure

    Mpa

    195

    158

    139

    Screw Speed

    Rpm

    0-165









    CLAMPING UNIT

    Clamp Force

    KN

    3980

    Space Between Tie Bars

    mm

    720*720

    Toggle Stroke

    mm

    700

    Max. Mold Height

    mm

    760

    Min. Mold Height

    mm

    280

    Ejector Stroke

    mm

    200

    Ejector Tonnage

    KN

    110

    Ejector Number

    P

    13





    OTHERS

    Max. pump Pressure

    Mpa

    16

    Pump motor powder

    Kw

    37

    Heater Power

    Kw

    24.8

    Machine Dimension(L*W*H)

    M

    7.3*2.0*2.2

    Oil Tank Capacity

    L

    850

    Machine Weight

    T

    16

      ねじ継手用射出成形機仕入れ・メーカー・工場 ねじ継手用射出成形機

     Some of the important features:
    • Clamping system:  Faster response, steable and high rigidity
    • Injection system:    Accurate and flexible, lower rejection rate
    • Control system:      Computer and simple operation,molding data memory system
    • Power system:        Energy saving, high efficient and precise
    • metal parts:              The thickness of our frame, metal plate and wallboard are thicker than other company.

    Other Information
    • Ceramic heating loop: Uniform heating, better thermal insulation properties so good for production
    • Visiable lubrication system:  on time clean, avoid cast steel parts abrasion and broken.
    • Oil treasure: Filter of hydraulic oil,good for pump and valves
    • Long working life: imported spare parts and updated version
    • Aftersales service: Professional & timely
    • Delivery time:30-60 days
    • Port of dispatch: Shanghai
