| 原産地: | 中国(本土) | 銘柄: | clw | 幅の舗装: | 4 メートル | 製品容量: | 0.2 〜 4.0 キログラム/m2 | モデル番号: | CLW5250TFCZ | 重量: | 25000 キログラム | 条件: | 新しい | 次元(L*W*H): | 10200*2500*3563 ミリメートル | 提供される売り上げ後のサービス: | 利用できるエンジニア機械類を海外に整備するため |
包装
| 包装: | ワックス |
[TECHNICAL SPECIFICATION] Vehicle Model CLW5250TFCZ | ||||||
| G.V.W(Kg) | 25000 | TANK CAPACITY(m3) | 8.1 | |||
| RATED LOAD(Kg) | 7500 | OVERALL DEMENSIONS(mm) | 10200×2500×3563 | |||
| CURB WEIGHT(Kg) | 17370 | ALLOWABLE PASSERGERS IN CAB | 2 | |||
| APPROACH/DEPARTURE ANGLE(°) | 16/14 | FRONT/REAR OVERHANG(mm) | 1500/2750,1500/2725 | |||
| NO. OF AXLES | 3 | WHEEL base(mm) | 4600+1350,4575+1400 | |||
| AXLES CAPACITY(Kg) | 7000/18000 | MAX. SPEED(Km/h) | 90 | |||
| HYDRANLIC PUMP | GPC4-50-25-20 | |||||
| GENERATOR | EG6500CXS(JAPAN) | ASPHALT PUMP | TGGM185-125(Belgium) | |||
| OTHERS | 1-Transport medium is liquid asphalt with density 970KGS/M3. | |||||
| 2-Elliptical tank dimensions(length/major axis/minor axis)(mm):2240/2190/1860 | ||||||
| 3-Thickness of tank thermal insulation 80mm) | ||||||
| 4-The cab can be chosen by different chassis. | ||||||
| 5-Protective material: carbon steel Q235A. | ||||||
| 6-Connection way: welding connection. | ||||||
| [CHASSIS SPECIFICATION] | ||||||
| CHASSIS MODEL | ZZ1257M4647C | CHASSIS TYPE | For truck(class 2) | |||
| BRAND | HOWO | MANUFACTURER | Sinotruk group jinan truck co., LTD | |||
| DEMENSIONS(mm) | 9895×2496×2958,3563 | NO. OF TYRES | 10 | |||
| APPROACH/DEPARTURE ANGLE(°) | 16/18 | TYRE SPECIFICATIONS | 11.00-20,12.00-20 16PR11.00R20 16PR,12.00R20 14PR | |||
| NO. OF SPRING PLATE | 10/12,4/12,10/- | FRONT TRACK base(mm) | 20,222,041 | |||
| FUEL TYPE | Diesel | REAR TRACK base(mm) | 1830/1830 | |||
| EMISSION STANDARD | GB17691-2005 GB ,GB3847-2005 | |||||
| ENGINE TYPE | ENGINE MANUFACTURER | DISPLACEMENT(ml) | POWER(Kw) | |||
| WD615.97E | Sinotruk group co., LTD | 9726 | 221 | |||
synchronous chip sealer
1, the same place for asphalt and chip landing time interval of not more than 1 second, greatly improve their caking ability;
2, asphalt tank and stone warehouse loading in the same chassis, reduces the cost;
3, fully automatic computer control;
4, the work of advancing direction and increase the safety of construction, the harm to the body greatly reduced, minimize the environmental impact .
